DMX operation

Setting the number of DMX channels and the DMX starting address
For operation with a controller with DMX512 protocol, the device is equipped with 310 control channels.
However, it can also be switched to a mode with 6, 17, 20, 21, or 298 channels if different functions are
required. To be able to operate the device with a DMX controller, the DMX starting address must be set. The
starting address depends upon which DMX controller is being used. Please refer to the controller's
documentation.
1 Press the MENU button so many times until Address is indicated on the display. Confirm with the
ENTER button.
2 Set the address via the UP and DOWN buttons and press the MENU button to return to the main menu.
3 Now press the MENU button so many times until Channel is indicated on the display.
4 The display indicates 6 CH (6DMX channels), 17 CH (17 DMX channels), 20 CH (20 DMX channels), 21
CH (21 DMX channels), 298 CH (298 DMX channels) or 310 CH (310 DMX channels). Use the buttons
UP and DOWN to select the desired DMX channel mode. Confirm with the ENTER button.
4 If no control signals are available, a * will blink on the display. The * will not blink when DMX signals are
being received
Note: Please make sure that you do not have any overlapping channels in order to control each device
correctly and independently from any other fixture on the DMX chain. If several devices are addressed to the
same address, they will work synchronously.
Functions in DMX mode
6-channel mode
Channel
1 000 – 255
000 – 005
2 006 – 250
251 – 255
3 000 – 255
4 000 – 255
5 000 – 255
6 000 – 255
Value Function
Master dimmer, 0-100%
No function
Strobe RGB with increasing speed 0-100%
No function
Red 0-100%
Green 0-100%
Blue 0-100%
White 0-100%
35/44 00140086, Version 1.0
