DESCRIPTION OF THE DEVICE

1
2
(1) LED SMD 5050 0,2W, RGB
(2) LED SMD 3535 3W, CW
(5) LC-display
(6) Safety eyelet
(7) Power input
(8) Fuse
(9) Power output
(10) UP button
(11) MENU button
6 7 8 9 10 11 12 13 14
27/44
(3) Fixation screw
(4) Mounting bracket
5
15 16
(12) ENTER button
(13) DOWN button
(14) DMX input 3-pin XLR
(15) DMX output 3-pin XLR
(16) DMX input 5-pin XLR
(17) DMX output 5-pin XLR
3
4
17
