EuroLite LED Mega Strobe 812 Panel Bedienungsanleitung Seite 33

Manual
In this mode, you can manually set the desired brightness and strobe speed, as well as the intensity of the
colors Red, Green, Blue and White.
1 Press the MENU button so many times until Manual is indicated in the display. Confirm with the ENTER
button.
2 The display shows Dimmer. Confirm with the ENTER button
3 Use the buttons UP and DOWN to select the desired brightness, from 000 (dark) to 255 (bright).
Confirm with the ENTER button.
4 The display now indicates Strobe. Confirm with the ENTER button.
5 Use the buttons UP and DOWN to adjust the strobe speed from 000 (slow) to 255 (fast). Confirm with
the ENTER button.
6 The display then shows Red. Confirm with the ENTER button
7 Use the buttons UP and DOWN to select the desired intensity, from 000 (dark) to 255 (bright). Confirm
with the ENTER button.
8 Continue this procedure to set the desired intensity for the colors green, blue and white.
With the MENU button you can return to the main menu.
Back L
With this function, you can adjust the display characteristics when the buttons are inactive:
1 Press the MENU button so many times until Back L is indicated in the display. Confirm with the ENTER
button.
2 Use the buttons UP and DOWN to select the desired setting and confirm with the ENTER button.
On – Display always on
60s - Shuts off the display after 60 seconds
120s - Shuts off the display after 120 seconds
300s - Shuts off the display after 300 seconds
With the MENU button you can return to the main menu.
Temp
With this function, device temperatures can be displayed.
1 Press the MENU button so many times until Temp is indicated in the display. Confirm with the ENTER
button.
2 Use the buttons UP and DOWN to select the desired temperature reading and confirm with the ENTER
button.
Temp 1: Displays the temperature on the LEDs.
Temp 2: Displays the inner temperature of the device.
With the MENU button you can return to the main menu.
33/44 00140086, Version 1.0
