Select the usage parameters using the up
SET P, T, FREQ
SET TIME
OPERATION MODE
SEQ PARAM SET
RST MAINT TIME
MAX RUN TIME
USER PASS:
LANG.
SET P, T, FREQ — set pressure and temperature
(Below are the example set values for the compressor with the max. 8-bar operating pressure).
P LOAD
P ULD
FREQ P
T FAN
T FAN STOP
RAT. POWER 75.0kW
RATED SPEED 2940RPM
SET TIME
FAN DELAY:
LOAD DELAY: 0002S
IDLE DELAY:
STOP DELAY:
START DELAY: 0040S
SPEED INCR:
SPEED DECR: 0625
Operational mode
RUN REMOTE/LOCAL
LOAD AUTO/MANUAL
COM: PC/BAN/GRP
COM ADDRESS: 001
+7 (800) 777-83-75(звонок бесплатный)
www.v-p-k.ru
05.2 BAR If the compressor is ready, it switches at this pressure to loaded running.
08.00 BAR At this pressure the compressor switches to idle running.
007.0 BAR Set pressure of the frequency inverter.
0095°C Switch-on temperature of the fan.
0060°C Switch-off temperature of the fan.
Rated power of the electric motor.
Rated speed of the electric motor.
0002S Delay in overloading fan.
Delay in load run (suction valve open).
0300S Idle run time. Suction valve closed, and main motor running.
0005S Switch-off delay with off button. Suction valve closed, and main motor running.
Delay in restart. Drop in system pressure.
0625 PID setting for the maximum speed increase.
PID setting for maximum speed reduction.
Switch on by remote control or locally via the control.
Loaded running/idle running automatically or manually.
Communication mode: PC / MODBUS / group.
Communication port, network address.
and down buttons and enter .
