GB
46
BELT SANDER
The numbers in the following text refer to the
picture on page 2
Read the operating instructions
carefully before using this device.
Familiarise yourself with its functions
and basic operation. Service the device
as per the instructions to ensure that it
always functions properly. The
operating instructions and the
accompanying documentation must be
kept in the vicinity of the device.
Contents
1. Machine data
2. Safety instructions
3. Operation
4. Service and maintenance
1. MACHINE DATA
Technical specifications
Voltage
Frequency
Power input
No load sander paper speed
Sanding belt size
Sanding pad size
Weight
Lpa (Sound pressure)
Lwa (Sound power level)
Vibration value
Product information
Fig. A + B
The belt sander is the perfect tool to sand wood
and to grind iron, plastic or similar materials.
The belt sander must be used for the rough work,
for the normal sanding work an orbital sander
must be used.
1.
Rear handle
2.
Front handle
3.
Front belt roller
4.
Clamping lever
5.
Direction indicator
6.
Cover carbon brush
7.
On/off switch
8.
Blocking switch
Ferm
Ferm
9.
Dust collection opening
10. Dust bag
11. Drive belt cover
12. Adjusting knob aligning sanding belt
13. Sanding belt
Contents of the package
1
Belt sander
1 Sanding belts
1 Dust collection bag
1 Instruction manual
1 Safety instructions
1 Guarantee card
Check the machine, loose parts and accessories
for transport damage.
2. SAFETY INSTRUCTIONS
Explanation of symbols
Denotes risk of personal injury, loss of
life or damage to the tool in case of
non-observance of the instructions in
this manual.
230 V~
Indicates the presence of an electrical
50 Hz
voltage.
950 W
370 m/min
Wear eye protection.
75x533 mm
76x135 mm
3.65 kg
Specific safety instructions
94 dB(A)
107 dB(A)
•
If you are working with the sanding machine,
2.4 m/s
2
wear always ear protectors and dust mask.
•
The sanding machine is not suitable for wet
sanding.
•
Check if the switch is not in position "ON",
before you connect the mains plug to the
mains voltage.
•
Keep the mains lead always away from
moving parts of the tools.
•
Use safety glasses, especially when you sand
above your head.
•
Do not bring pressure to your machine, this
will only delay the sanding.
The dust that is produced while working
can be detrimental to health, inflam-
mable or explosive. Suitable safety
measures are required. Always wear
suitable safety equipment, for example
a dust mask, and use the dust bag.
GB
03
