W
ARNING:
Activities at height are inherently dangerous. Understand and
accept the risks involved before participating. You are responsible
for our own actions and decisions. Before using this product, read
and understand all instructions and warnings that accompany it
and familiarize with its proper use, capabilities and limitations. We
recommend that every climber seeks proper training in the use of
the equipment. Failure to read and follow these warnings can result
in severe injury or even death!
MARK 1 PLUS/MARK 1 TACTICAL is a self-breaking descender for
single rope use and is certified according to the norms EN 341:2011,
Class A and EN 12841:2006 Type C. While the former norm is
meant for rescue purposes only later implies rope access.
USE: rescue, intervention, industry, sport: rope access, independent
descent, assisted descent, emergency evacuations, work at height...
EN341:2011
Tests according to the norm EN 341:2011 have been performed
with the INOBELT SUPER STATIC Ø 11 mm.
min. rated load (kg)
max. rated load (kg)
max. descent dist. m
nr. of consecutive descents
sheath slippage
elongation (E)
mass per metre (M)
sheath proportion (Sp)
core proportion (C)
shrinkage (R)
material
Tested and approved for descents with a released energy of 7,5 MJ
(according to EN 341 class A):
W=m x g x h x n
Approved Temperature range and rated loades:
Dry rope: -20°C ≤ T ≤ 60°C, 30 kg ≤ rated load ≤ 160 kg
wet rope: -4°C ≤ T ≤ 60°C, 50 kg ≤ rated load ≤ 160 kg
EN12841:2006 Type C
Certified for use with static (EN 1891 Type A) ropes with diameters
between 9 mm and 12 mm.
Diameter
9 mm
10 mm - 12 mm
8
m: mass (kg)
g: acceleration of gravity= 9,81m/s
h: height (m)
n: number of descents
Maximum rated load
130 kg
200 kg
30
160
190
25
≤ 2,1 %
≤ 5 %
75 g/m
39%
61%
2,5%
PA
2
