How to replace the heat exchanger,
Procedure, continued
8
Step
6 Remove the filter above the heat ex-
changer
7 Remove the rubber insulating roll
above the heat exchanger
>
2012
8 Lift up carefully the heat exchanger
and pull it carefully out
9 Take the new heat exchanger.
Place the heat exchanger in the unit.
Note that the arrow on the heat ex-
changer must be visible from the front
and point upwards
10 Remount the filter (note the direction of the arrows)
11 Remount the styrene front, the cross bars, the front covers and the basic user
panel
12 Connect the power again
continued
Action
