Process Data Input (Device  Master) - Siko AP05 Benutzerhandbuch

IO-Link
Sub- Name
index
8 bc05_ErrorAck
9 bc06_Reserved
10 bc07_Reserved
11 bc08_Reserved
12 bc09_TargetValueActive
13 bc10_Reserved
14 bc11_Led1Green
15 bc12_Led1Red
16 bc13_Led2Green
17 bc14_Led2Red
18 bc15_LedBlinking
Tabelle 23: Process data output bei Betriebsart Absolute Position
Process data input (Device  Master)
5.1.1.2
Sub- Name
index
1 PositionValue
2 Reserved
3 bs00_DirIndicationCW
4 bs01_DirIndicationCCW
5 bs02_CalibrationExecuted
6 bs03_Reserved
7 bs04_GuardingBit
8 bs05_TargetWindowReached 53
9 bs06_Deviation
10 bs07_GeneralError
11 bs08_Reserved
12 bs09_IncMeasurement
13 bs10_TargetValueState
AP05
Datum: 22.08.2022
Bit- Bit- Data-
offset Länge type
53 1 Bool
54 1 Bool
55 1 Bool
56 1 Bool
57 1 Bool
58 1 Bool
59 1 Bool
60 1 Bool
61 1 Bool
62 1 Bool
63 1 Bool
Bit- Bit- Data-
offset Länge type
0 32 Signed-
Integer
32 16 -
48 1 Bool
49 1 Bool
50 1 Bool
51 1 Bool
52 1 Bool
1 Bool
54 1 Bool
55 1 Bool
56 1 Bool
57 1 Bool
58 1 Bool
Art. Nr. 90884 Änd. Stand 108/22
Bemerkung
If true the actual error is
acknowledged
Used in DisplayMode
Used in DisplayMode
Used in DisplayMode
If true TargetValue is
active
If true LED is on.
Function controlled via
Parameter LEDMode
siehe bc11
siehe bc11
siehe bc11
If true LEDs are blinking
when on
Bemerkung
Absolute position value
True if indicator cw is on
True if indicator ccw is
on
True if calibration was
executed by command via
interface
Used in DisplayMode
Communication guarding
True if target window is
reached
Deviation from actual
value to target
True if error occurred
Used in DisplayMode
True if incremental
measurement is active
True if target value is
active
