Pin Plug Function
Code
13 S 1 Status 1
11 S 2 Status 2
9 C1 G Remote Control wire 4
Option Box wire brown
CBG Easy GND
7 C1 L Remote Control wire 3
Option Box wire yellow
CBG Easy Detect
5 C1 H
Remote Control wire 2
Option Box wire green
3
1 - St Temperature Control-
led
Charging
Extern Start / Stop
Pin Plug Function
Code
14 Dete
12 C2 G
10 13 V 13 V
O
Power Sup-
ply
VCC
8 C2 L Air Puls
6 C2 H
4
2 + St Temperature Controlled
Charging
Extern Start / Stop
Remote Control
wire 1
Option Box wire
white
CBG Easy
Air Puls
Status
