5
Montage / Mounting
5.5
Schritt 4
* Siehe Seite 7 oder 8
See page 7 or 8
13
5.5
*
*
*
*
21b
21b
21c
21b
Baumer_HOGS100_T1_DE_EN_202109_MI_11081756 (21A1)
Step 4
Zul. Anzugsmoment
einseitig offene Hohlwelle:
Max. tightening torque
blind hollow shaft:
M
= 6 Nm
t
Zul. Anzugsmoment
Konuswelle:
Max. tightening torque
cone shaft:
M
= 3...4 Nm
t
17 mm
4
*
*
21a
19
*
19
5 mm
*
*
5
10 mm
*
*
21b
21c
MB183aT1 - 11081756
