Zip HydroTap® G5 CS100
4. Installation
EN

5. Use

Cold water lever
Chilled, sparkling
water
SELECT
SAFETY
Zip lever
14. Register the appliance online at www.clage.com.
Note: If the water system has not been used for several days, allow the tap to run
cold water for about five minutes.
Sparkling water lever

Operation

Classic
Press the blue 'chilled' lever to dispense chilled water (max. 15 sec.). Pull the lever up
to dispense chilled water continually. The water will flow for 5 to 15 seconds. This time
can be set in the menu. The lever then has to be manually returned to the Off position.
Press the blue 'sparkling' lever to dispense sparkling water with carbon dioxide added
(max. 15 sec.). Pull the lever up to dispense sparkling water continually. The water will
flow for 5 to 15 seconds. This time can be set in the menu. The lever then has to be
manually returned to the Off position.
Classic Plus
White filter LED
Press the blue button to dispense chilled water. When the button is pressed, chilled
water flows as long as it is pressed (max. 15 sec.).
Press the white button to dispense sparkling water. When the button is pressed,
sparkling water flows as long as it is pressed (max. 15 sec.).
Quantity filling: Before selecting the water type, press the fill button. After pressing the
red, blue or white button briefly, water flows for a period of between 5 and 15 seconds
that can be set in the menu.
Touch-Free
Hold your hand approx. 1.5 – 5 cm in front of the right sensor to dispense cooled water.
Chilled water flows as long as the hand is held in the sensor area (max. 15 sec.). If the
rear sensor is also triggered, water flows for a period of between 5 and 15 seconds that
can be set in the menu.
Hold your hand approx. 1.5 – 5 cm from the top over the tap to dispense carbonated
sparkling water. Sparkling water flows as long as the hand is held in the sensor area
(max. 15 sec.). If the rear sensor is also triggered, water flows for a period of between 5
and 15 seconds that can be set in the menu.
Note: To ensure smooth functioning of the sensor tap, make sure there is a free
space of min. 10 cm around the sensor head.
Arc / Celsius Arc
Select the desired type of water by tipping to on the Select button on the ZIP lever at
the tap.
• Blue: chilled water
• White: sparkling water
Turn the lever to dispense water. When the lever is turned counterclockwise, water will
flow as long as the lever is held (max. 15 sec.). If the lever is turned clockwise, water
will flow continually for 5 to 15 seconds. This time can be set in the menu. The lever
then has to be manually returned to the Off position.
30
