Description Of Appliance; Technical Data - clage Zip HydroTap G5 CS 100 Gebrauchs- Und Montageanleitung

Zip HydroTap® G5 CS100

2. Description of Appliance

The Zip HydroTap® G5 CS100 is an electronically controlled system which deliver filtered boiling water as well as chilled still and
sparkling water for kitchens and pantries. The appliance itself is stowed away out of sight below the sink and the water is dispensed
via a special tap. The Classic, Classic Plus, Touch-Free, and Arc tap can be positioned alongside the kitchen tap or separately with
a flat draining tray, as desired. The Celsius Arc tap replaces the kitchen tap because also the ambient hot and cold water can be
EN
tapped on it.
Arc

3. Technical Data

Model
Rated voltage / rated power
Rated pressure
Cold water temperature range
Sparkling water volume
Carbon dioxide rated pressure
Water connection
Size (H × W × D)
Weight (filled)
Ambient temperature
Coolant / quantity
Protection class according to VDE
Type of protection
* ) Connecting hose G ½" with Adapter G ⅜" supplied.
Classic Touch-Free
MPa / bar
°C
MPa / bar
cm
kg
°C
Zip HydroTap® G5 CS100
Classic Plus
Zip HydroTap® G5 CS100
230 V AC / 0.37 kW
0.25 – 0.70 / 2.5 – 7.0
5 – 10
Instantaneous carbonisation
0.3 / 3.0
G ½" or G ⅜"
33.3 × 28.0 × 48.0
36,5
5 – 35
R290 / 76 g
Class I
IP20
22
*
)
