Selection for both circuits and discharge temperature control
Code
Parameter description and choices
Et
Valve type
0 = EXM / EXL
1 = EXN (not permitted for R454A)
NOTE: EXD-HP2 can drive two similar valves i.e. both valves must be either
EXM/EXL or EXN.
1E3
Discharge Temperature Setpoint
Start Setpoint
1E4
Discharge Temperature Control band
1E5
Discharge Temperature limit
1E6
Max. condensing pressure
1E7
Injection Pressure Limit
1E8
High injection pressure alarm delay (s)
M O P T a b l e ( ° C )
Refrigerant
Min.
Max.
R22
-40
+50
R134a
-40
+66
R410A
-40
+45
R32
-40
+30
R407C
-40
+48
R290
-40
+50
R448A
-57
+66
R449A
-57
+66
E r r o r / A l a r m H a n d l i n g
Alarm code Description
1E0/2E0
Pressure sensor 1/2 error
1E1/2E0
Temperature sensor 1/2 error
Discharge hot gas
1Ed
temperature sensor 3 error
EXM/EXL or EXN electrical
1Π-/2Π-
connection error
Discharge hot gas
1Ad
temperature above limit
1AF/2AF
Freeze protection
1AF/2AF
blinking
1AL/2AL
Low superheat
1AL/2AL
(<0,5K)
blinking
1AH/2AH
High superheat
1AP/2AP
Low pressure
1AP/2AP
blinking
High injection pressure
1Ai
circuit 1
Failed
Err
uploading/downloading
NOTE: When multiple alarms occur, the highest priority alarm is displayed until being cleared, then the next highest alarm is displayed until all alarms are cleared. Only then will parameters be shown
