OPERATION

Turn on the device. The display indicates the last operating mode. The operating modes can be selected by
means of the display and the control buttons. All settings remain stored even if the device is disconnected
from the mains. The device can be operated in stand-alone mode via the control board and the EUROLITE
IR-7 remote control or in DMX-controlled mode via any commercial DMX controller, or QuickDMX per USB.

Menu structure

Press the MENU button so many times until the desired function is indicated on the display. Use the ENTER
button to select the function. With the buttons UP and DOWN you can select the mode or change values.
Confirm with ENTER.
Mode
DMX mode
Preset colors
Automatic mode
Sound control
Running speed in
automatic mode and
sound control
Microphone sensitivity
for sound control
Individual color mix
Dimmer
Silent scene
Behaviour in case of
missing DMX signal
Slave mode
ECO PRO
IR remote control
Version
Display
96CH
48CH
Addr 8CH
5CH
3CH
Stat S 01-17
Auto Au 01-12
Soun So 01-12
SPEE SP 1-9
SEnS SE 1-9
r000-255
Colo g000-255
b000-255
diMM dI 1-dI 9
on
SILE
oFF
blaC
hold
Lost FuLL
Stat
Auto
SLAV SLAU
on
ECo
oFF
on
InFr
oFF
V1.0 V1.0
28/36
d001-512 96-channel mode and start address
d001-512 48-channel mode and start address
d001-512 8-channel mode and start address
d001-512 5-channel mode and start address
d001-512 3-channel mode and start address
Constant lighting in one of 17 colors
Auto program
Sound program
Program running speed
slow > fast
Microphone sensitivity
low > high
Red 0-100%
Green 0-100%
Blue 0-100%
Total brightness
dark > bright
LEDs off during periods without
music or bass-beat
Program continues automatically
during periods without music or
bass-beat
LEDs go off
Spot holds the last received signal
All LEDs 100% on
Pre-selected static color 01-17
Pre-selected auto program 01-12
Slave mode
Energy saving mode
Regular mode
IR remote control on
IR remote control off
Current software version 1.0
Function
