Wireless DMX transmission with QuickDMX
The device features an alternative DMX input for a QuickDMX receiver (sold separately). This connector
allows for wireless transmission of DMX control signals to the device. The connector is designed as a USB
port which provides the required 5 V operating voltage for the receiver. With QuickDMX devices, extensive
cabling between the DMX controller and the device is not required.
Occupation of the USB port:
Charging the battery pack
Prior to operating the device off mains for the first time, the rechargeable battery must be fully charged. You
can charge the product using the power cable.
1
Switch on the device with the power button. The operating time of the battery depends on the operating
mode and the ambient temperature (max. 9 hours). After the operation, switch the device off.
2
For charging the battery, connect the device to a power outlet via the power adapter provided. Charging
time is 1.5 hours. The device may be operated during the charging procedure.
3
The device features a protective circuit for charging which prevents overload of the rechargeable battery.
However, disconnect the device from the mains after charging. Otherwise there will be a low current
consumption even if the device is switched off.
4
The device will heat up during charging; this is normal.
5
To prevent damage to the battery by deep discharge, recharge a completely discharged battery as soon
as possible. Do not store the unit with the battery completely discharged and regularly recharge the
battery in case of long storage.
Maximum battery run time
9 hours
Battery status
The battery charge status is indicated via the battery charge indicator above the display. The battery charge
status is indicated by four levels. The first light (25%) is always red. If three levels light up green and the first
level red, the battery is fully charged. If only one is still green, the battery will be going flat soon. The device
can be operated in this state for several minutes. Afterwards a protection circuit against deep discharge
automatically switches off the device.
Recharge time
1.5 hours
27/36
00133960, Version 1.1
