COMPOUND MITRE / TABLE SAW FCTM-250N
The numbers in the following text correspond with the pictures at page 2 - 4.
Before using the machine, thoroughly read these instructions for use. Make sure
that you know how the machine works and how to operate it Maintain the machine
according to the instructions and make sure that it works properly. Keep these
instructions for use and the other documentation with the machine.
Introduction
The bench circular saw / Compound mitre saw is for sawing wood and woody pieces of work.
Contents
1. Machine information
2. Safety
3. Assembly and accessories
4. Operating
5. Service and Maintenance

1. MACHINE INFORMATION

Technical specifications
Voltage
Capacity
Machine class
Revolutions, not under load
Saw blade measurement
Angle for mitring
Angle for bevelling
Table saw maximum sawing capacity
Compound mitre saw maximum sawing capacity
M itre 0º, Bevel 0º
Mitre 45º, Bevel 45º
Mitre 45º, Bevel 0º
Mitre 0º, Bevel 45º
Weight
Lpa (sound pressure)
Table saw
Compound mitre saw
Lwa (acoustic capacity
Table saw
Compound mitre saw
Vibration level
Ferm Ferm
UK
230 V ~, 50 Hz
1400 W
II (double insulated)
4000/min
250 x 30 x 3.2mm
45º (left and right)
45º (only left)
42 mm
130 x 70mm
55 x 35mm
85 x 70mm
127 x 38mm
23 kg
94.1 dB(A)
94.4 dB(A)
107.1 dB(A)
107.4 dB(A)
0.4 m/s 2
