SIDE EXTENSION TABLE (FIG. A6)
The side extension table increases the distance from the rip fence to
the blade to 600 mm or more, depending on the rod length fitted to the
machine and the clamped position of the table. The side extension table
must be used in conjunction with guide rails (29) (option).
The adjustable table is equipped with an engraved scale along its front
edge and mounted on a sturdy base which clamps to the guide rods.
• Fit the extension table to the right-hand side of the machine for
continuity of the distance scale on both tables.
SINGLE SLIDING TABLE (FIG. A7)
This sliding table (37) allows for board sizes to the left of the blade up to
1200 x 900 mm.
The guide rods are mounted on a sturdy alloy extrusion which is quickly
detachable from the machine and yet fully adjustable is all planes.
The fence incorporates a full length measuring tape for quick positioning
of an adjustable stop and an adjustable support for narrow workpieces.
DOUBLE SLIDING TABLE
This sliding table allows for board sizes to the left of the blade up to
1850 mm.
Transporting
WARNING: Always transport the machine in bench saw
mode with the upper blade guard fitted.
• Remove the legs.
WARNING: When carrying the machine, always use the
hand indentations (fig.A1;40) and seek for assistance. The
machine could be too wide protruding for one person to
handle.
MAINTENANCE
Your D WALT power tool has been designed to operate over a long
E
period of time with a minimum of maintenance. Continuous satisfactory
operation depends upon proper tool care and regular cleaning.
WARNING: To reduce the risk of injury, turn unit off
and disconnect machine from power source before
installing and removing accessories, before adjusting
or changing set-ups or when making repairs. Be sure
the trigger switch is in the OFF position. An accidental start-
up can cause injury.
Lubrication
The bearings of the motor are pre-lubricated and watertight.
• Slightly oil the rotating table bearing surface where it slides on the
lip of the fixed table at regular intervals.
• Clean the parts subject to accumulation of sawdust and chips
periodically with a dry brush.
Cleaning
WARNING: Blow dirt and dust out of the main housing
with dry air as often as dirt is seen collecting in and around
the air vents. Wear approved eye protection and approved
dust mask when performing this procedure.
WARNING: Never use solvents or other harsh chemicals
for cleaning the non-metallic parts of the tool. These
chemicals may weaken the materials used in these parts.
Use a cloth dampened only with water and mild soap.
Never let any liquid get inside the tool; never immerse any
part of the tool into a liquid.
WARNING: To reduce the risk of injury, regularly clean
the table top.
WARNING: To reduce the risk of injury, regularly clean
the dust collection system.
Before use, carefully check the upper blade guard, movable lower
blade guard as well as the dust extraction tube to determine that it will
operate properly. Ensure that chips, dust or workpiece particle cannot
lead to blockage of one of the functions.
In case of workpiece fragments jammed between saw blade and
guards disconnect the machine from the power supply and follow the
instructions given in section Mounting the Saw Blade. Remove the
jammed parts and reassembling the saw blade.
Optional Accessories
WARNING: Since accessories, other than those offered
by D WALT, have not been tested with this product, use
E
of such accessories with this tool could be hazardous.
To reduce the risk of injury, only D
accessories should be used with this product.
SAW BLADES
ALWAYS USE noise reduced 250 mm SAW BLADES WITH 30 mm
ARBOR HOLES. SPEED RATING MUST BE AT LEAST 3000 RPM.
Never use a smaller or greater diameter blade. It will not be guarded
properly. Use cross cut blades only. Do not use blades designed for
fast ripping, combination blades or blades with hook angles in excess
of 10°.
BLADE DESCRIPTIONS
APPLICATION
Construction Saw Blades (thin kerf with anti-stick rim)
General Purpose
Woodworking Saw Blades (provide smooth, clean cuts)
Fine crosscuts
Consult your dealer for further information on the appropriate
accessories.
Protecting the Environment
Separate collection. This product must not be disposed of
with normal household waste.
Should you find one day that your D
or if it is of no further use to you, do not dispose of it with household
waste. Make this product available for separate collection.
Separate collection of used products and packaging allows
materials to be recycled and used again. Re-use of
recycled materials helps prevent environmental pollution
and reduces the demand for raw materials.
Local regulations may provide for separate collection of electrical
products from the household, at municipal waste sites or by the retailer
when you purchase a new product.
D WALT provides a facility for the collection and recycling of D
E
products once they have reached the end of their working life. To take
advantage of this service please return your product to any authorised
repair agent who will collect them on our behalf.
You can check the location of your nearest authorised repair agent by
contacting your local D WALT office at the address indicated in this
E
manual. Alternatively, a list of authorised D
full details of our after-sales service and contacts are available on the
Internet at: www.2helpU.com.
ENGLISH
WALT, recommended
E
DIAMETER TEETH
250 mm 30 (Series 60)
250 mm 60 (Series 60)
WALT product needs replacement,
E
WALT
E
WALT repair agents and
E
