3 First Steps
3.1. Connection
overview
www.balluff.com
Figure 3-1: BNI IOL-309/310-000-K024/K025
1 IO-Link Interface
2 Port 1-8/16 Input/Output
3 Port 1-8/16 24V
4 Port 1-8/16 GND
5 Status LED: Port 1-8/16
6 Status LED: Communication
7 Status LED: Supply Module
8 Status LED: Supply Module AUX
