1 Preliminary note
Symbols used
►
Instructions
>
Reaction, result
→
Cross-reference
Important note: Non-compliance may result in malfunction or interference.
Information; Supplementary note.
2 Safety instructions
Installation, electrical connection, set-up, operation and maintenance of the unit must be carried out by qualified person-
nel authorised by the machine operator.
3
Functions and features
Ultrasonic sensors detect objects of various materials without any contact. Depending on the selected sensor, detected
objects are signalled via switching outputs or their distance is indicated by means of a proportional analogue signal.
4 Installation
1: Status LED P1 (yellow)
2: Echo LED (green)
► Position object.
► Align the ultrasonic sensor so that it directly faces the object or the background and secure it to a bracket.
>
Object / background is detected when the echo LED (green) lights.
Sound-absorbing surfaces have a negative effect on a reliable function.
During installation of the device, consider the blind zone.
1: Sensor
2: Target (object to be detected)
3: Sensing range
4: Blind zone
12
3: Set button
