Bedienungsanleitung
DE
Strömungswächter
UK
Operating instructions
FR
Flow monitor
Notice d'utilisation
Capteur de débit
AS001
autosen

Werbung

Inhaltsverzeichnis
loading

Inhaltszusammenfassung für autosen AS001

  • Seite 1 All manuals and user guides at all-guides.com Bedienungsanleitung Strömungswächter Operating instructions Flow monitor Notice d'utilisation Capteur de débit AS001 autosen...
  • Seite 2: Inhaltsverzeichnis

    All manuals and user guides at all-guides.com Inhalt 1 Vorbemerkung �����������������������������������������������������������������������������������������������������3 1�1 Zeichenerklärung �������������������������������������������������������������������������������������������3 2 Sicherheitshinweise ���������������������������������������������������������������������������������������������4 3 Bestimmungsgemäße Verwendung ���������������������������������������������������������������������4 3�1 Einsatzbereich ����������������������������������������������������������������������������������������������4 3�2 Funktionsweise Strömungsüberwachung ������������������������������������������������������4 3�3 Funktionsweise Temperaturüberwachung �����������������������������������������������������5 4 Montage ���������������������������������������������������������������������������������������������������������������6 4�1 Montageort ����������������������������������������������������������������������������������������������������6 4�2 Störeinflüsse im Leitungssystem �������������������������������������������������������������������7 4�3 Montagevorgang ��������������������������������������������������������������������������������������������7 5 Elektrischer Anschluss �����������������������������������������������������������������������������������������8 6 Bedien- und Anzeigeelemente �����������������������������������������������������������������������������9...
  • Seite 3: Vorbemerkung

    All manuals and user guides at all-guides.com 9 Fehlerbehebung�������������������������������������������������������������������������������������������������16 10 Wartung �����������������������������������������������������������������������������������������������������������17 11 Technische Daten ��������������������������������������������������������������������������������������������17 1 Vorbemerkung 1.1 Zeichenerklärung ► Handlungsanweisung > Reaktion, Ergebnis → Querverweis Wichtiger Hinweis Fehlfunktionen oder Störungen sind bei Nichtbeachtung möglich� Information Ergänzender Hinweis� LED leuchtet grün LED leuchtet orange LED leuchtet rot LED blinkt...
  • Seite 4: Sicherheitshinweise

    All manuals and user guides at all-guides.com 2 Sicherheitshinweise • Lesen Sie vor der Inbetriebnahme des Gerätes dieses Dokument� Vergewis- sern Sie sich, dass sich das Produkt uneingeschränkt für die betreffenden Applikationen eignet� • Die Missachtung von Anwendungshinweisen oder technischen Angaben kann zu Sach- und/oder Personenschäden führen�...
  • Seite 5: 3�3 Funktionsweise Temperaturüberwachung

    All manuals and user guides at all-guides.com • Steigt die Strömungsgeschwindigkeit, ändert sich der Schaltzustand bei Errei- chen des Schaltpunkts� • Sinkt die Strömungsgeschwindigkeit wieder, ändert sich der Schaltzustand, wenn der Wert "SP minus Hysterese" erreicht ist� Die Hysterese verändert sich mit der Strömungsgeschwindigkeit und sie wird wesentlich beeinflusst vom eingestellten Erfassungsbereich�...
  • Seite 6: Montage

    All manuals and user guides at all-guides.com 4 Montage Durch Prozessadapter ist das Gerät adaptierbar an unterschiedliche Prozessan- schlüsse� • Adapter sind gesondert als Zubehör zu bestellen� 4.1 Montageort Generell • Die Sensorspitze soll vollständig vom Medium umflossen werden� • Eintauchtiefe des Messfühlers: minde- stens 12 mm�...
  • Seite 7: 4�2 Störeinflüsse Im Leitungssystem

    All manuals and user guides at all-guides.com 4.2 Störeinflüsse im Leitungssystem Einbauten in der Rohrleitung, Krümmungen, Ventile, Reduzierungen u� ä� führen zu Verwirbelungen des Mediums� Dies beeinträchtigt die Funktion des Geräts� Empfehlung: Abstände einhalten zwischen Sensor und Störeinflüssen: 5...10 x D 3...5 x D Flow High...
  • Seite 8: Elektrischer Anschluss

    All manuals and user guides at all-guides.com 5 Elektrischer Anschluss Das Gerät darf nur von einer Elektrofachkraft installiert werden� Befolgen Sie die nationalen und internationalen Vorschriften zur Errichtung elektrotechnischer Anlagen� Spannungsversorgung nach EN 50178, SELV, PELV� ► Anlage spannungsfrei schalten� ►...
  • Seite 9: Bedien- Und Anzeigeelemente

    All manuals and user guides at all-guides.com 6 Bedien- und Anzeigeelemente Flow High 0 1 2 3 4 5 6 7 8 [x10°C] Setpoint Flow Temp 1: Betriebsanzeige • Die grünen LEDs zeigen die aktuelle Strömung (die LEDs 0 bis 9 repräsentieren den Bereich zwischen Strömungsstillstand und Maximalströmung)�...
  • Seite 10: 7�1�2 Gerätespezifische Informationen

    All manuals and user guides at all-guides.com 7.1.2 Gerätespezifische Informationen Die zur Konfiguration des IO-Link-Gerätes notwendigen IODDs sowie detaillierte Informationen über Prozessdatenaufbau, Diagnoseinformationen und Parameter- adressen finden Sie unter www�autosen�com 7.1.3 Parametrierwerkzeuge Alle notwendigen Informationen zur benötigten IO-Link-Hardware und Software finden Sie unter www�autosen�com...
  • Seite 11: 7�3 Schaltpunkt Sp1 Für Strömung Verändern (Optional)

    All manuals and user guides at all-guides.com Normalströmung unterschreitet den Darstel- lungsbereich des Displays� Flow High 2 Einstellmöglichkeiten: ► Schaltpunkt verändern (→ 7.3). 0 1 2 3 4 5 6 7 8 [x10°C] ► High Flow-Abgleich durchführen (→ 7.4). Normalströmung überschreitet den Darstel- Flow High lungsbereich des Displays (LED 9 blinkt)� ►...
  • Seite 12: 7�5 Schaltpunkt Sp2 Für Temperatur Einstellen

    All manuals and user guides at all-guides.com ► Taste loslassen� Damit ist das Gerät an die Strömungsverhältnisse angepasst� Es geht in den Betriebsmodus, das Display sollte nun Beispiel 1 zeigen� Der Abgleich beeinflusst den Schaltpunkt: Er wird proportional erhöht (maximal bis auf LED 7)� 7.5 Schaltpunkt SP2 für Temperatur einstellen ►...
  • Seite 13: 7�6 Low Flow-Abgleich (Optional)

    All manuals and user guides at all-guides.com 0 1 2 3 4 5 6 7 8 [x10°C] 0 1 2 3 4 5 6 7 8 [x10°C] Nach Erreichen der LED 0 beginnt der Durchlauf der blinkenden LED wieder bei LED 9; die stetig leuchtende LED (Zehnerstelle) wandert eine Position nach links (wenn eingestellt wird mit )�...
  • Seite 14: 7�8 Werkseinstellung Wieder Herstellen (Reset)

    All manuals and user guides at all-guides.com > Nach 10 s wird die aktuelle Einstellung angezeigt: LEDs 5���9 leuchten orange (= Ausgänge in Schließerfunktion)� > Nach ca� 15 s blinken LEDs 0���4 orange� ► Taste loslassen� Die Ausgänge sind umgestellt auf Öffnerfunktion� Für erneute Umstellung: Vorgang wiederholen�...
  • Seite 15: Betrieb

    All manuals and user guides at all-guides.com 8 Betrieb Nach jedem Einschalten der Versorgungsspannung leuchten alle LEDs auf und verlöschen wieder schrittweise (während dieser Zeit sind die Ausgänge geschlos- sen, wenn sie als Schließer konfiguriert sind)� Danach ist das Gerät betriebsbereit� Bei Ausfall oder Unterbrechung der Betriebsspannung bleiben alle Einstellungen erhalten�...
  • Seite 16: 8�3 Störanzeigen

    All manuals and user guides at all-guides.com 8.3 Störanzeigen Kurzschluss an Schaltausgang OUT1 Betriebsanzeige und 5 rote LEDs links leuchten 0 1 2 3 4 5 6 7 8 [x10°C] im Wechsel� Ist der Kurzschluss behoben, geht das Gerät sofort 0 1 2 3 4 5 6 7 8 [x10°C] wieder in den normalen Betriebszustand�...
  • Seite 17: Wartung

    ► Sensorspitze von Zeit zu Zeit auf Ablagerungen überprüfen� ► Mit einem weichen Tuch reinigen� Fest anhaftende Ablagerungen (z� B� Kalk) lassen sich mit handelsüblichem Essigreiniger entfernen� 11 Technische Daten Technische Daten und Maßzeichung unter www�autosen�com� Weitere Informationen unter www�autosen�com...
  • Seite 18 All manuals and user guides at all-guides.com Contents 1 Preliminary note �������������������������������������������������������������������������������������������������19 1�1 Explanation of symbols ��������������������������������������������������������������������������������19 2 Safety instructions ���������������������������������������������������������������������������������������������20 3 Functions and features ��������������������������������������������������������������������������������������20 3�1 Applications ������������������������������������������������������������������������������������������������20 3�2 Operating principle flow monitoring �������������������������������������������������������������20 3�3 Operating principle temperature monitoring ������������������������������������������������21 4 Installation����������������������������������������������������������������������������������������������������������22 4�1 Installation location ��������������������������������������������������������������������������������������22 4�2 Interference in the pipe system �������������������������������������������������������������������23...
  • Seite 19: Preliminary Note

    All manuals and user guides at all-guides.com 9 Troubleshooting �������������������������������������������������������������������������������������������������32 10 Maintenance ����������������������������������������������������������������������������������������������������33 11 Technical data ��������������������������������������������������������������������������������������������������33 1 Preliminary note 1.1 Explanation of symbols ► Instructions > Reaction, result → Cross-reference Important note Non-compliance can result in malfunction or interference� Information Supplementary note�...
  • Seite 20: Safety Instructions

    All manuals and user guides at all-guides.com 2 Safety instructions • Please read this document prior to set-up of the unit� Ensure that the product is suitable for your application without any restrictions� • If the operating instructions or the technical data are not adhered to, personal injury and/or damage to property can occur�...
  • Seite 21: 3�3 Operating Principle Temperature Monitoring

    All manuals and user guides at all-guides.com The hysteresis changes with the flow speed and it is essentially influenced by the set monitoring range� It is 2���5 cm/s for the setting 5���100 cm/s (= factory setting), it increases with higher flow speeds� • The typical response time of the unit is 1���10 s�...
  • Seite 22: Installation

    All manuals and user guides at all-guides.com 4 Installation Using process adapters the unit can be adapted to different process connections� • Adapters have to be ordered separately as accessories� 4.1 Installation location General • The sensor tip is to be completely surrounded by the medium�...
  • Seite 23: 4�2 Interference In The Pipe System

    All manuals and user guides at all-guides.com 4.2 Interference in the pipe system Components integrated in the pipes, bends, valves, reductions, etc� lead to turbu- lence of the medium� This affects the function of the unit� Recommendation: Adhere to the distances between sensor and sources of inter- ference: 5...10 x D 3...5 x D...
  • Seite 24: Electrical Connection

    All manuals and user guides at all-guides.com 5 Electrical connection The unit must be connected by a qualified electrician� The national and international regulations for the installation of electrical equipment must be adhered to� Voltage supply according to EN 50178, SELV, PELV� ►...
  • Seite 25: Operating And Display Elements

    All manuals and user guides at all-guides.com 6 Operating and display elements Flow High 0 1 2 3 4 5 6 7 8 [x10°C] Setpoint Flow Temp 1: Operation indication • The green LEDs indicate the current flow (LEDs 0 to 9 represent the range between flow standstill and maximum flow)�...
  • Seite 26: 7�1�2 Device-Specific Information

    You will find the IODDs necessary for the configuration of the IO-Link unit and detailed information about process data structure, diagnostic information and parameter addresses at www�autosen�com� 7.1.3 Parameter setting tools You will find all necessary information about the required IO-Link hardware and software at www�autosen�com�...
  • Seite 27: 7�3 Change Switch Point Sp1 For Flow (Optional)

    All manuals and user guides at all-guides.com Your normal flow is below the representation range of the display� Flow High 2 setting options: ► Change the switch point (→ 7.3). 0 1 2 3 4 5 6 7 8 [x10°C] ► Carry out high-flow adjustment (→ 7.4). Your normal flow exceeds the representation Flow High range of the display (LED 9 flashes)�...
  • Seite 28: 7�5 Set Switch Point Sp2 For Temperature

    All manuals and user guides at all-guides.com The unit is now adapted to your flow conditions� It returns to the operating mode, the display should now show example 1� The adjustment affects the switch point: it is increased proportionally (maxi- mum up to LED 7)�...
  • Seite 29: 7�6 Low-Flow Adjustment (Optional)

    All manuals and user guides at all-guides.com After LED 0 has been reached the cycle of the flashing LED starts again at LED 9; the continuously lit LED (tens digit) moves one position to the left (when setting is made with )�...
  • Seite 30: 7�8 Restore The Factory Setting (Reset)

    All manuals and user guides at all-guides.com Using an IO-Link capable parameter setting tool, the outputs can be sepa- rately set as normally closed or normally open� 7.8 Restore the factory setting (reset) ► Press for at least 15 s� >...
  • Seite 31: Operation

    All manuals and user guides at all-guides.com 8 Operation After every power on all LEDs light and go out again step by step (during this time the outputs are closed if configured as normally open)� The unit is then ready for operation�...
  • Seite 32: 8�3 Interference Indicators

    All manuals and user guides at all-guides.com 8.3 Interference indicators Short circuit at switching output OUT1� The operating indicator and 5 red LEDs on the left light alternately� 0 1 2 3 4 5 6 7 8 [x10°C] If the short circuit has been rectified, the unit imme- 0 1 2 3 4 5 6 7 8 [x10°C] diately passes into the normal operating state�...
  • Seite 33: Technical Data

    ► Check the sensor tip for build-up from time to time� ► Clean it using a soft cloth� Stubborn build-up (e�g� lime) can be removed using a common vinegar cleaning agent� 11 Technical data Technical data and scale drawing at www�autosen�com� More information at www�autosen�com...
  • Seite 34 All manuals and user guides at all-guides.com Contenu 1 Remarques préliminaires �����������������������������������������������������������������������������������35 1�1 Explication des symboles ����������������������������������������������������������������������������35 2 Consignes de sécurité ���������������������������������������������������������������������������������������36 3 Fonctionnement et caractéristiques �������������������������������������������������������������������36 3�1 Application ��������������������������������������������������������������������������������������������������36 3�2 Fonctionnement surveillance du débit ���������������������������������������������������������36 3�3 Principe de fonctionnement surveillance de température ����������������������������37 4 Montage �������������������������������������������������������������������������������������������������������������38 4�1 Lieu de montage ������������������������������������������������������������������������������������������38 4�2 Parasites dans la conduite ��������������������������������������������������������������������������39...
  • Seite 35: Remarques Préliminaires

    All manuals and user guides at all-guides.com 9 Correction de défauts ����������������������������������������������������������������������������������������48 10 Entretien ����������������������������������������������������������������������������������������������������������49 11 Données techniques ����������������������������������������������������������������������������������������49 1 Remarques préliminaires 1.1 Explication des symboles ► Action à faire > Retour d'information, résultat → Référence croisée Remarque importante Le non-respect peut aboutir à des dysfonctionnements ou perturbations� Information Remarque supplémentaire�...
  • Seite 36: Consignes De Sécurité

    All manuals and user guides at all-guides.com 2 Consignes de sécurité • Lire cette notice avant la mise en service de l'appareil� S'assurer que le produit est approprié pour l'application concernée sans aucune restriction d'utilisation� • Le non-respect des consignes ou des données techniques peut provoquer des dommages matériels et/ou corporels�...
  • Seite 37: 3�3 Principe De Fonctionnement Surveillance De Température

    All manuals and user guides at all-guides.com • Si la vitesse du fluide diminue de nouveau, l'état de commutation change quand la valeur " SP moins l'hystérésis " est atteinte� L'hystérésis change en fonction de la vitesse et dépend considérablement de la zone de détection réglée�...
  • Seite 38: Montage

    All manuals and user guides at all-guides.com 4 Montage L'adaptateur process permet le raccordement de l'appareil à différents raccords process� • Les adaptateurs sont à commander séparément comme accessoires� 4.1 Lieu de montage En général • Le bout de la sonde doit être complète- ment couvert par le fluide�...
  • Seite 39: 4�2 Parasites Dans La Conduite

    All manuals and user guides at all-guides.com 4.2 Parasites dans la conduite Des éléments présents dans le tube, des coudes, des vannes, des réductions de diamètre et d'autres choses semblables mènent à des perturbations du fluide� Ceci affecte le fonctionnement de l'appareil� Recommandation : respecter des distances entre le capteur et les perturbations : 5...10 x D 3...5 x D...
  • Seite 40: Raccordement Électrique

    All manuals and user guides at all-guides.com 5 Raccordement électrique L'appareil doit être monté par un électricien qualifié� Les règlements nationaux et internationaux relatifs à l'installation de matéri- el électrique doivent être respectés� Alimentation en tension selon EN 50178, TBTS, TBTP� ►...
  • Seite 41: Eléments De Service Et D'indication

    All manuals and user guides at all-guides.com 6 Eléments de service et d'indication Flow High 0 1 2 3 4 5 6 7 8 [x10°C] Setpoint Flow Temp 1: Affichage de fonctionnement • Les LED vertes indiquent le débit actuel (les LED 0 à 9 représentent la gamme entre l'arrêt du débit et le débit maximal)�...
  • Seite 42: 7�1�2 Informations Spécifiques À L'appareil

    Vous trouverez les IODD nécessaires pour la configuration de l'appareil IO-Link ansi que des informations détaillées concernant la structure des données process, des informations de diagnostic et les adresses des paramètres sur www�autosen�com� 7.1.3 Outils de paramétrage Vous trouverez toutes les informations nécessaires concernant le matériel et logiciel IO-Link sur www�autosen�com�...
  • Seite 43: 7�3 Changer Le Seuil De Commutation Sp1 Pour Le Débit (Option)

    All manuals and user guides at all-guides.com Le réglage usine est approprié pour Flow High l'application� ► Pour la surveillance du débit un autre 0 1 2 3 4 5 6 7 8 [x10°C] réglage n'est pas nécessaire� Le débit normal est en dessous de la zone d'affichage�...
  • Seite 44: 7�5 Régler Le Seuil De Commutation Sp2 Pour La Température

    All manuals and user guides at all-guides.com ► Activer le débit normal dans l'installation� ► Appuyer sur le bouton et le maintenir appuyé� > LED 9 s'allume, après env� 5 s elle clignote� ► Relâcher le bouton� Ceci est l'adaptation optimale de l'appareil aux conditions de débit� Il passe en mode de fonctionnement, l'afficheur devrait maintenant indiquer l'exemple 1�...
  • Seite 45: 7�6 Réglage Au Débit Minimum (Option)

    All manuals and user guides at all-guides.com Si la LED 9 est atteinte, le cycle recommence à la LED 0 ; la LED allumée en permanence (1ère position) est décalée d'une position vers la droite (en cas de réglage par )�...
  • Seite 46: 7�8 Récupérer Les Réglages De Base Effectués En Usine (Reset)

    All manuals and user guides at all-guides.com > LED 0 s'allume, après env� 5 s elle clignote� > Après 10 s, le réglage actuel est affiché : les LED 5���9 sont allumées en oran- ge (= sorties en fonction normalement ouvert)� >...
  • Seite 47: Fonctionnement

    All manuals and user guides at all-guides.com Cette fonction ne peut être réglée qu'à l'aide d'un logiciel de paramétrage et ne peut pas être réglée directement sur l'appareil� 8 Fonctionnement Après chaque mise sous tension, toutes les LED s'allument et s'éteignent de nouveau pas à...
  • Seite 48: 8�3 Indication De Défauts

    All manuals and user guides at all-guides.com LED 0 clignote : débit actuel bien en dessous de la zone d'affichage� 0 1 2 3 4 5 6 7 8 [x10°C] 8.3 Indication de défauts Court-circuit sur la sortie de commutation OUT1 L'affichage de fonctionnement et les 5 LED rouges 0 1 2 3 4 5 6 7 8 [x10°C]...
  • Seite 49: Données Techniques

    ► Vérifier périodiquement la présence éventuelle de dépôts en bout de sonde� ► Nettoyer avec un chiffon doux� Des dépôts adhérents (p�ex� chaux) peuvent être enlevés avec un produit acétique de nettoyage usuel� 11 Données techniques Données techniques et schéma d'encombrement sur www�autosen�com� Plus d'informations à www�autosen�com...
