Position the mounting plate (E) on the desired
•
site on the wall. Make sure that the arrow on the
mounting plate is pointing upwards.
Use a pen to mark the positions of bore holes (I)
•
(diagonally opposite) in the mounting plate on
the wall (see figure 5).
• Now drill the bore holes.
If you are working with a stone wall, drill the
marked two 5 mm holes and insert the plugs sup-
plied. If you are working with a wooden wall, you
can pre-drill 1.5 mm holes to make screws easier
to insert.
Use the supplied screws and plugs (J) to fasten
•
the mounting plate to the wall (see figure 6).
• Attach the clip-on frame (A) to the mounting
plate.
Place the sensor (B) back into the frame (see fig-
•
ure 1). Make sure that the clips on the mounting
plate latch into the openings on the sensor.
5.2.3

Mounting on flush-mounted boxes

You can mount the temperature and humidity sensor on
flush-mounting/installation boxes using the holes (H)
(see figure 4).
