Firmware update
Download the latest Firmware Update from the manufacturer's website.
Rename the downloaded file into "Dimmermaster.upd" and save it on your USB media in the folder
"Dimmermaster".
Switch the controller off.
Press and hold the Run Mode-button, Program-button and the Up-button.
Switch the controller on.
Press any key. The display will show "Update firmware OK".
Switch the controller off.
RDM
With this function you can set the DMX starting address via RDM.
This device is RDM ready. RDM stands for "Remote Device Management" and makes remote control of
devices connected to the DMX-bus possible. ANSI E1.20-2006 by ESTA specifies the RDM standard as an
extension of the DMX512 protocol.
Manual settings like adjusting the DMX starting address are no longer needed. This is especially useful when
the device is installed in a remote area.
RDM is integrated n the DMX-protocol without influencing the connections. The RDM-data is transmitted via
the standard XLR-poles 1 and 2 – new DMX-cables are not necessary. RDM ready and conventional DMX
devices can be operated in one DMX line. The RDM protocol sends own packages in the DMX512 data feed
and does not influence conventional devices.
If DMX splitters are used and RDM control is to be used, these splitters must support RDM.
Press and hold the Run Mode-button and the Program-button.
The controller is scanning the DMX-line for RDM-ready devices.
When RDM-devices are found, the display shows the name and the starting address.
Select the desired device via Playback 1 and Playback 2.
Press the Up and Down-buttons in order to adjust the new starting address.
Press the Program-button in order to send the new starting address to the device.
Repeat the above steps for all other devices.
Press and hold the Run Mode-button and the Program-button in order to leave the RDM-mode.

7. PROBLEM CHART

PROBLEM
No power.
Cannot memorize Scene.
Cannot edit programs.
Programmed scene/chaser
disappeared.
Cannot display
scene/chaser.
No signal output.
CAUSE
The power unit is not connected.
Program-button forgotten.
Program mode locked.
Selected wrong page.
Wrong fader-setting.
Blackout-mode activated.
19/20
REMEDY
Check the connection cable of the
power unit and any extension-cables.
Press the Program-button after setting
the channels.
Unlock program mode.
Select correct page via the Page-
button.
Adjust Master-fader to maximum, the
Fade-fader and Wait Time-Fader to
the desired setting.
Switch off blackout by pressing the
Blackout-button.
00065864.DOC, Version 1.0
