Waste Time CHG/DCHG 1min:
The battery becomes warm after cycles of charge/discharge process.
The program will insert a time delay after each charge/discharge pro-
cess to allow the battery enough time to cool down before beginning
next cycle of charge/discharge process. The valid value ranges from 1
to 60 minutes. The factory default is set to 1 minute.
To change the factory setting of 1min press the enter key and change the
flashing value with the -DEC/+INC-keys. Safe the set value with the enter key.
To go on with the basic setting press the -DEC/+INC-keys:
Trickle Charge
You can set the trickle charge mode on or off. If it is on, the charger
will automatically supply the trickle charge current to achieve the full
charge without overheating the battery after fast charge has been
terminated.
Safety Timer ON 120min:
When the charge process starts, the integrated safety timer starts to run simultaneously. When
this time is passed, the process is stopped independent of the charging condition.
First select whether you want to switch the safety timer ON or OFF. Press the enter key an
change the flashing value to ON or OFF with the -DEC/+INC-keys. Save this setting by pressing
the enter key.
The flashing value of the minutes (press the enter key twice) should be set or calculated as
follows to make sure, that your battery is really fully charged:
Example:
Capacity Current
2000mAh 2,0A
3300mAh 3,0A
5000mAh 5,0A
Einstellung
Save the setting by pressing the enter key.
Recommendation: Use the safety timer only when charging the same
types of batteries with the same capacity.
To go on with the basic setting press the -DEC/+INC-keys:
Setting of the minutes
2000:2,0=1000 > 1000:11,9(formula) = 84min Your setting
3300:3,0=1100 >1100:11,9(formula) = 92min Your setting
5000:5,0=1000 > 1000:11,9(formula) = 84min Ihre
