6.4. TERMINAL-BOARD CN4
6.4.1. o a
Pen
Terminals "OPENA / COM2". Normally open contact. Connect, to these terminals, any pulse generator (e.g. push-button,
selector, etc..) which, by closing the contact, commands the gate to totally open or close. The operation of this input
is defined by dip-switch 5 - see paragraph 10.
• If there are several pulse generators, connect them in parallel.
6.4.2. o B
Pen
Terminals "OPENB / COM2". Normally open contact. Connect, to these terminals, any pulse generator (e.g. push-button,
selector, etc..) which, by closing the contact, commands the gate to partially open. Partial opening corresponds to
50% of the total memory-stored opening.
•If there are several pulse generators, connect them in parallel.
6.4.3. s
toP
Terminals "STOP / COM2". Normally closed contact. Connect, to these terminals, any safety device (push-button, pressure
switch etc.) which, by opening the contact, acts on gate motion, causing motion to reverse for 1 second before stopping
movement, by disabling all the automatic functions. The status of this input is signalled by the "STOP" LED.
• If no device is connected, jumper-connect the inputs.
• If several safety devices are present, connect them in series.
6.4.4. P
hotocells
Terminals "FSW / COM2". Normally closed contact. Connect, to these terminals, any safety device (photocell, edge,
pressure switch, etc..) which, by opening the contact, acts on gate motion. This input can be active only during the
closing stage or also during the opening stage, according to how dip-switch 4 is selected (see paragraph 10). For the
behaviour of safety devices, see paragraph 13 (operating logics). The status of this input is shown by "FSW" LED.
• If no safety device is connected, jumper-connect the inputs.
6.5. TERMINAL-BOARD CN5
6.5.1. a
ntenna
Connect the external antenna, if any, to these terminals. Connect the antenna cable and the relevant shielding as
shown on the board's screen-printing.
The SPRINT control unit has a built-in receiver board. It operates only with the appropriate remote-controls. For
programming and deleting the radio channel, follow the instructions below.
7.1. SAVING THE CODE
1- Power up the system.
2- Press and hold down "MEMO RX" push-button. The flashing lamp lights up on steady beam and indicates entry to
the saving stage.
3- On the remote-control, press the push-button for the channel you wish to save - the flashing lamp flashes to indicate
that the push-button has been saved.
4- Release the radio-control push-button and the "MEMO RX" push-button: the flashing lamp goes off and you have
exited the saving mode.
5- To save the next remote-controls, repeat from point 2.
7.2. DELETING RADIO CODES
During the deleting stage, you can delete one channel only or all the saved codes.
7.2.1. d
eleting a radio code
Procedure for deleting one radio code only:
1- Press and hold down the "MEMO RX" push-button: the flashing lamp lights up on steady beam
2- After 10 seconds, press (on the radio control) the push-button for the channel you wish to delete: the flashing lamp
flashes for 5 seconds.
3- Release the remote control push-button and the "MEMO RX" push-button on the control unit: the flashing light goes
off.
7.2.2. d
eleting all radio codes
Procedure for deleting all the saved codes:
1- Press and hold down the "MEMO RX" push-button: the flashing lamp lights up on steady beam
2- After 30 seconds, press any push-button on the radio control: the flashing lamp flashes for 10 seconds.
3- Release the remote control push-button and the "MEMO RX" push-button on the control unit: the flashing lamp
goes off.
