6.1. TERMINAL-BOARD CN1
6.1.1. P 22V~
ower suPPly
Terminals "VAC - VAC". Connect the cables of the transformer's secondary circuit to these terminals. Mains power
supply "ON" is signalled by the "POWER" LED located under the terminal-board.
6.1.2. B
atteries
Terminals "+BAT / -BAT". Connect the power cables of the buffer batteries (optional) to these terminals. The control
unit is designed to operate with two buffer batteries with the characteristics shown on the table in paragraph 2.
During normal operation, the control unit keeps the batteries charged - the batteries come into operation in the event of
a mains power cut.
• Power supply from the batteries only should be considered an EMERGENCY situation. The number of possible
manoeuvres is linked to the quality of the batteries, the structure of the gate to be moved, how long ago the
power cut occurred, etc., etc. .
• The two batteries must be connected to each other in series.
• Observe the polarity of the batteries.
6.1.3. a
ccessories
Terminals "+AAC / -ACC". Connect the accessories power cables to these terminals.
• The maximum load of the accessories must not exceed 500mA.
• The output of these terminals is on direct power. When connecting the accessories, observe correct
polarity.
6.1.4. e
arth
Terminal " ". Connect the control unit earthing line to this terminal.
• This connection is absolutely necessary to ensure a correctly operating control unit.
6.2. TERMINAL-BOARD CN2
6.2.1. F
lashing lamP
Terminals "LAMP / LAMP". Connect the flashing lamp with 24Vdc max 15W power supply to these terminals.
Before every manoeuvre, the flashing lamp pre-flashes for 0.5 sec.
• We advise you to connect the flashing lamp before programming the board, because it indicates - by a
series of flashes - the different programming stages of both the control unit and the receiver.
• Use a steady beam flashing lamp; flashing is controlled by the control unit itself.
6.2.2. m
otor
Terminals "CHM1 / APM1". Connect the motor power cables to these terminals.The maximum load of the motor must
not exceed 70W.
6.3. TERMINAL-BOARD CN3
6.3. e
ncoder
Terminals "SIG / +ENC / -ENC". Connect, to these terminals: the signal sent from the encoder and the two power
cables.
• The encoder must be connected to ensure operation of the control unit
6.3.2. c
losure limit switch
Terminals "COMF / FCC": Normally closed contact. Connect, to these terminals, the gate closure limit-switch. The switch
intervenes by stopping the gate closing movement. The status of this input is signalled by "FCC" LED.
6.3.3. o
Pening limit switch
Terminals "COMF / FCA". Normally closed contact. Connect, to these terminals, the gate opening limit-switch. The switch
intervenes by stopping the gate opening movement. The status of this input is signalled by "FCA" LED.
• Both limit-switches must be connected to ensure correct operation of the control unit.
• The "COMF" contact must be used strictly as a common contact of the limit-switches.
