TRAINING IN MORE THAN ONE
TRANSMITTER (MAX. 8 DEVICES)
1. Insert a battery (CR 2477) into the TRANSMITTER
to be tuned in.
2. Press and hold the sensor (4) on the receiver for
2 seconds. The CLOSED LED (5) begins to blink.
3. Activate the TRANSMITTER by holding the magnet
against the housing once and then removing it. The
POWER LED on the RECEIVER stops blinking and the
tuning-in procedure is completed.
4. Repeat steps a), b) and c) for each individual
transmitter.
5. Once a maximum of 8 TRANSMITTERS is tuned in,
it is impossible to add any more.
DELETING ONE OR ALL TRANSMITTERS
(MAX. 8 DEVICES)
Deleting individual TRANSMITTERS
1. Press and hold the sensor (4) on the receiver for
2 seconds. The CLOSED LED (5) begins to blink.
2. Activate the TRANSMITTER to be deleted by holding
the magnet against the housing once and then
removing it. The POWER LED on the RECEIVER stops
blinking and the deletion procedure is completed.
Deleting all TRANSMITTERS
1. Press and hold the sensor (4) on the receiver for
2 seconds. The CLOSED LED (5) begins to blink.
2. Press and hold the sensor (4) once more for
2 seconds. The POWER LED on the RECEIVER stops
blinking and the deletion procedure for all
TRANSMITTERS is completed.

FUNCTIONAL TEST

With (OpEN) operating direction:
1. Switch exhaust air device ON and open the window >
exhaust air device must switch on.
2. Close the window > exhaust air device must switch off.
With (CLOSE) operating direction:
1) Switch connected device ON and open the window >
the connected device must switch off.
2) Close the window > the connected device must switch on.
MALFUNCTIONS
In individual cases cross-over with other similar
radio devices can cause malfunctions. In the normal
case it is sufficient to check the positioning of the
components and if necessary, to modify this.

TECHNICAL DATA

Mains voltage:
Mains switching capacity:
Radio range up to:
Frequency:
Transmitting power:
protection class:
Batterie (transmitter):
230 V ~ , 50/60 Hz,
approx. 1 W
1000 W/5 A, at cos phi =1
100 m
433.92 Mhz
< 10mW
IP 20 only for dry rooms
1 x 3V Lithium Typ
CR 2477 (lifetime approx.
2 years)
