to enable the lighting to function independently of the
receiver switch status (see diagram).
ATTENTION
Always check that the power rating of the connected
device is less than or equal to the switching capacity.
TRANSMITTER INSTALLATION
Preparation
Mount transmitter (2) and magnet (3) on the upper
window frame and the window sash in such a way that
the distance between the two housing components is
less than 7 mm. Use the supplied washers (U)
for adjustment.
Window area in m
m 0,2 0,3
2
cm 2000 3000
2
Maximum permissible exhaust air performance in m
5 cm 199 252
6 cm 246 311
7 cm
294 369
8 cm 342 427
9 cm 389 486
10 cm 437 544
11 cm
485 603
12 cm 532 661
(Table 1) Calculation table to determine the minimum opening of your window
2
0,4 0,5 0,6 0,7
4000 5000 6000 7000
297 337 373 406
365 413 456 495
538 585
432 488
500 563 621 674
567 639 704 763
635 714 786 852
702 790 869 942
770 865 951 1031
1. Mount the transmitter housing base at the determined
position, using the supplied double-sided adhesive pad.
Alternatively, there is a blanked hole in the bottom of
the housing. Remove the circuit board from the bottom
of the housing and carefully break open the hole. Use
the hole to screw the transmitter to the window frame.
Then replace the circuit board.
2. Press the upper part of the housing onto its base.
3. Mount the magnet housing bottom in the determined-
position, using the supplied adhesive pad.
ATTENTION
The distance between the transmitter and the
magnet must not exceed 7 mm!
4. Insert magnet and close with the housing cover.
0,8 0,9 1 1,1
8000 9000 10000 11000
/h
3
437 466 493 519
532 567 600 631
628 668 707 743
723 770 813 855
819 871 920 967
914 972 1027 1079
1009 1073 1133 1191
1105 1174 1240 1302
1,2 1,3 1,4 1,5
12000 13000 14000 15000
544 568 591 613
661 690 717 744
778 811 843 874
970 1005
895 933
1012 1055 1096 1136
1128 1176 1222 1266
1245 1298 1348 1397
1362 1419 1475 1528
