Protector AS-6020.3 Betriebsanleitung Seite 10

WIRELESS EXHAUST AIR CONTROL AS-6020.
TRANSMITTER WINDOW
2a
U
3
10
2 3
Open the casing by lifting the
side with a screwdriver
2
3
You can fix the window transmitter and the magnet
U
housing with included adhesive pads or screws.
When using one or more washers at the magnet housing,
e.g. for compensating window frames, we recommend
the window transmitter and the magnet housing to be
fastened with screws to avoid an unwanted falling off.
(See drawing)
3a
3b
3c
U
2 3
U
