RCMB42...
Allstromsensitives Differenzstrom-Überwachungsgerät
i
Bestandteil der Gerätedokumentation sind neben
dieser Kurzanleitung die „Sicherheitshinweise für
Bender-Produkte" und das dazugehörige Handbuch,
herunterladbar unter https://www.bender.de/ser-
vice-support/downloadbereich.
Die Kurzanleitung ersetzt nicht das Handbuch!
Lieferumfang
1 RCMB42..., 1 bzw. 2 Messstromwandler, Montageclip
(1x), Kurzanleitung DE/EN, Sicherheitshinweise
Bestellangaben
Messbereich/
Measuring range
f
DC
RMS
0...6
0...30
0...
mA
mA
2000 Hz
Montageclip für Schraubmontage (1 Stück je Gerät, Zubehör)
Mounting clip for screw mounting (1 piece per device, accessories)
Bestimmungsgemäße Verwendung
Das allstromsensitive Differenzstrom-Überwachungsgerät
RCMB42... wird zur Überwachung von DC-Fehlerströmen
eingesetzt, die größer als DC 6 mA sind. Die gerätespezi-
fischen Versorgungsspannungen U
Daten zu entnehmen.
Eine andere oder darüber hinausgehende Benutzung gilt
als nicht bestimmungsgemäß.
RCMB42x_D00167_00_Q_DEEN/07.2021
Messstromwandler/
Measuring CTs
(Ø 15 mm, 1.5 m Kabel/cable)
2
1
sind den Technischen
S
RCMB42...
AC/DC sensitive residual current monitor
i
Part of the device documentation in addition to this
quickstart is the enclosed "Safety instructions for
Bender products" and the manual, downloadable at
https://www.bender.de/en/service-support/down-
loads.
The quickstart guide does not replace the manual!
Scope of delivery
1 RCMB42..., 1 resp. 2 measuring CTs, Mounting clip (1x),
Quickstart guide DE/EN, Safety instructions
Ordering information
Kanäle/
Versorgungsspg U
Channels
Supply voltage U
AC 110...240 V, 50/60 Hz;
DC 150...220 V
2 x I
Δn
DC 18...36 V
AC 110...240 V, 50/60 Hz;
1 x I
DC 150...220 V
Δn
DC 18...36 V
Indended Use
The AC/DC sensitive residual current monitor RCMB42... is
used for DC-fault current monitoring, where the amount
can be greater than DC 6 mA.The device specific supply
voltage U
are described in the Technical Data.
S
Any use other than that described in this manual is regar-
ded as improper.
*
Art.-Nr.
Typ /Type
s
*
Art.-No.
s
RCMB420-2 B74042500
RCMB420-25 B74042503
RCMB422-2 B74042502
RCMB422-25 B74042504
B98060008
Kurzanleitung / Quickstart guide DE/EN
Handbuch Nr.
Manual No.
D00167
-
