Saw blade guard / splitter
•
Push stick
•
Parallel stop
•
Hand wheel
•
Crank arm
•
Rubber foot (4x)
•
Cross stop
•
Screw for parallel stop (2x)
•
Stop rail for parallel stop
•
Knurled screw for parallel stop (2x)
•
Leg (4x)
•
Cross strut (4x)
•
Additional leg (2x)
•
Wrench, size 10/13 mm
•
Wrench, size 10 mm
•
Hex screw (8x)
•
Washer, large (8x)
•
Lock bolt (8x)
•
Washer, small (12x)
•
Spring washer (8x)
•
Nut (12x)
•
Screw with washer and spring washer (4x)
•
Original operating instructions
•
Safety information

3. Proper use

The bench-type circular saw is designed for the
slitting and cross-cutting (only with the cross
stop) of all types of timber commensurate with the
machine's size. The equipment is not to be used
for cutting any type of round wood.
The equipment is to be used only for its prescri-
bed purpose. Any other use is deemed to be a
case of misuse. The user / operator and not the
manufacturer will be liable for any damage or inju-
ries of any kind caused as a result of this.
Please note that our equipment has not been de-
signed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.
The equipment is to be operated only with suita-
ble saw blades (saw blades made of HM or CV)
It is prohibited to use any type of HSS saw blade
and cutting-off wheel.
To use the equipment properly you must also
observe the safety information, the assembly
instructions and the operating instructions to be
Anl_TC_TS_254_ECO_SPK9.indb 26 Anl_TC_TS_254_ECO_SPK9.indb 26
GB
found in this manual.
All persons who use and service the equipment
have to be acquainted with these operating
instructions and must be informed about the
equipment's potential hazards. It is also imperati-
ve to observe the accident prevention regulations
in force in your area. The same applies for the
general rules of health and safety at work.
The manufacturer will not be liable for any chan-
ges made to the equipment nor for any damage
resulting from such changes. Even when the
equipment is used as prescribed it is still impossi-
ble to eliminate certain residual risk factors.
The following hazards may arise in connection
with the machine's construction and design:
•
Contact with the saw blade in the uncovered
saw zone.
•
Reaching into the running saw blade (cut
injuries).
•
Kick-back of workpieces and parts of work-
pieces.
•
Saw blade fracturing.
•
Catapulting of faulty carbide tips from the saw
blade.
•
Damage to hearing if essential ear-muffs are
not used.
•
Harmful emissions of wood dust when used
in closed rooms.

4. Technical data

AC motor ..................................220-240V ~ 50Hz
Power P ..................S1 1800 W · S6 40% 2050 W
Idling speed n ..................................... 4250 rpm
0
Carbide saw blade .......... Ø 254 x Ø 30 x 2.4 mm
Number of teeth ............................................... 24
Table size ...................................... 580 x 555 mm
Cutting height max. ........................... 80 mm / 90°
........................................................ 55 mm / 45°
Height adjustment .................... infi nite 0 - 80 mm
Tilting saw blade .......................... infi nite 0° - 45°
Cross stop angle ....................... infi nite -45° - 45°
Extractor connection .............................Ø 36 mm
Weight ........................................ approx. 19.1 kg
Protection class: ........................................... II/
Thickness of the splitter .......................... 2.0 mm
