LED Display

The LEDs of the UTN server provide information about its status.
LED Action
Link permanently on
permanently off
Activity blinks at
irregular
intervals
Status permanently off
blinks 3 times
blinks 2 times
Power permanently on
permanently off
USB ports permanently off
1–3
permanently on
permanently on
Important:
During the activation procedure, the behavior of the
LEDs differs from this description.

Type Plate

The type plate gives important product information, such as hardware and
certification information as well as the serial number. The serial number
contains the production date: nnn YYYY MM nnnnn.
This information helps you e.g. during maintenance and you need it for support
requests as well as for the guarantee extension.
Quick Installation Guide
Color Description
green There is a connection to the network.
– There is no connection to the
network.
yellow Indicates the exchange of network
data packets.
– If the activity LED blinks periodically
at the same time, the BIOS mode is
signalized.
green Indicates the assignment of a
Zeroconf IP address.
green Indicates the assignment of an IP
address that does not correspond to
0.0.0.0 or that comes from outside
the Zeroconf range.
yellow The device is powered.
– The device is not powered.
– No USB device is connected to the
respective port.
green A USB device is connected to the
respective port.
orange The connection to the respective
port and the attached USB device is
activated.
