3. Installation

NOtICE
The interplay between the racing shell and the
adapter is crucial to how the entire seat system
behaves.
„ Install the RECARO Profi SPG XL racing shell
only with the independently tested RECARO
adapter 7207000A.
Only this provides the necessary safety in
motor sports.

3.1. Positioning the racing shell in the vehicle

„ Select the most comfortable seat position for
yourself that is safest for driving the vehicle:
You must be able to completely hold the top
edge of the steering wheel without lifting yourself
out of the seat with your back.
Your knee must still be slightly angled when the
clutch is fully pressed.
„ Make sure that the restraint systems and the roll
cage are correctly installed (see the manufac­
turer's installation instructions).

3.2. Scope of delivery

„ Check the scope of delivery for completeness
before installation
Racing shell (Figure A)
(1) Racing shell, 1 ea.
(2) front seat cushion, 1 ea.
(3) Back seat cushion, 1 ea.
(4) Rest cushion, 1 ea.
Adapters (Figure B)
Aluminum adapter 7207000A
(5) Adapter, 2 ea.
(6) Washer, 4 ea.
(7) Screw M8x20, 10.9, 4 ea.

3.3. Installation sequence

Refer to Page 3 for the associated
drawings.
Aligning the adapters
NOtICE
On each of the insides of the two adapters there
is a black arrow on a white background
„ install the adapters in the vehicle so that the
arrows point in the driving direction.
The arrow must point in the driving
direction.
Mounting the adapters in the vehicle
NOtICE
The adapters must be secured in the vehicle
and the associated structural modifications to
the vehicle must be done in accordance with the
stipulations of the respective national motorsport
organisation or the FIA as per the respective ap­
plicable version of the regulations that apply.
„ install the adapters in the vehicle with
4 M8 screws, strength class 10.9.
Tightening torque: 35 Nm.
Fixing the racing shell (Figure C)
1. Position the racing shell (1) between the
adapters (5).
2. Set the seat height by selecting the rear
holes (a, b).
3. Fix the racing shell at the rear on the adapter
with the washer (6) and screw M8x20 (7).
When doing this, only tighten the screws hand­
tight.
Aligning the racing shell (Figure C)
1. Set the seat incline by selecting the front
holes (c, d, e, f).
2. Fix the racing shell at the front on the adapters
with the washer (6) and screw M8x20 (7).
