26 - English

Installing and removing the loudspeaker (optional)

You can install an additional loudspeaker in your device.
If you are also installing the SmartCard reader, install the SmartCard
reader before the loudspeaker.

Installing the loudspeaker

Loudspeaker
The required hexagon head bolts are included in the delivery scope of the loudspeaker.
► Open the housing (see
► If a PCI or PCIe board is installed, remove the cross piece and PCI or PCIe
board (see "Removing the board", Page 38 -
► Secure the hexagon head bolts provided into the screw holes (1).
► Insert the loudspeaker into the housing as illustrated.
68
"Opening the casing", Page 20 - English).
English).
1
1
Fujitsu Technology Solutions
System expansions
