Your Coboc bike is equipped with a modern lithium-ion battery. This type
of battery offers the best state-of-the-art energy density, which means
maximum reach at minimum weight. Furthermore, lithium-ion batteries
have no memory effect. This battery has a nominal voltage of 36 volts and
a nominal capacity of 380 Wh.
The battery on your Coboc bike is installed into the bikes frame.
This way of installation allows for a very low vehicle weight while
providing ideal protection against moisture. The battery remains in
the frame even for charging. Only trained personnel is allowed to remove
the battery.
Do not remove the battery by yourself! Under no circumstances
should the cover at the bottom of the down tube be opened.
Only trained personnel should carry out maintenance or repairs
on the installed drive system. Carrying out maintenance or repairs may
result in danger to life due to live parts such as cables and contacts.
Furthermore, the drive system is being protected against moisture by a
special sealing technology, which is why warranty obligations become
invalid if the down tube is being opened without the approval by Coboc.

Range

The range of your Coboc bike is heavily dependent on various influencing
factors and can therefore fluctuate. These include the following factors,
among others: the type of surface, incline/slope of the route, wind condi-
tions, tire characteristics, air pressure, rider weight, cadence, riding speed
and temperature. The settings of the drive parameters also have an impact
on the range of your Coboc bike. Information about the Coboc app and
the setting of the individual drive parameters can be found here: www.
coboc.biz/en/coboc-app/.
Battery & Charger
With a fully charged battery and on level terrain, preset mode 1 (blue
LEDs) can be used to achieve approx. 70-100 km. When riding on asphalt
roads, a low tire pressure can increase the rolling resistance and thus
reduce the range. Headwinds or hilly terrain will also have a negative im-
pact on the range. Increasing the drive parameters via the Coboc app will
express itself in stronger support but in return in a shorter range. A higher
total weight will also reduce the range of your Coboc bike. If you ride over
25km/h in return, the motor support is switched off and you ride your bike
like a normal bike. This increases the remaining range accordingly.
On hot days (battery temperature of more than 60° C) the battery turns
itself off for safety reasons. After that, it has to cool down before you are
able to use it again. If your bike has not been turned on or charged for
more than 30 days, it automatically sets itself into a deep sleep mode in
order to save battery power. If in deep sleep mode, your Coboc bike can
not be turned on. However, you can reactivate it first by plugging in the
charger.
Battery level is displayed on the user interface. Up to five LEDs light up
after turning on the Coboc bike. They are split up as follows:
5 LEDs are lit up in blue
4 LEDs are lit up in blue
3 LEDs are lit up in blue
2 LEDs are lit up in blue
1 LEDs are lit up in blue
If more than one LED is flashing red this indicates an error within
the drive system. See chapter "Error codes" for more insight.
battery level of 80 % to 100 %
g
battery level of 60 % to 80 %
g
battery level of 40 % to 60 %
g
battery level of 20 % to 40 %
g
battery level of 1 % to 20 %
g
