Concept VP 836X Bedienungsanleitung Seite 37

EN
EN
CLEANING AND REPLACING THE AIR OUTLET FILTER
CLEANING AND REPLACING THE AIR OUTLET FILTER
1. Open the air outlet grid in the appliance's rear section (Fig. 4).
1. Open the air outlet grid in the appliance's rear section (Fig. 5).
2. Remove the air outlet filter. You can clean this filter by tapping it, then brushing it
2. Remove the air outlet filter. This type of vacuum cleaner is equipped with a
with a soft brush. After this operation is complete, you may clean a very dirty filter by
H.E.P.A. filter in the outlet, which is capable of catching even very fine dust
washing and brushing with a soft brush in lukewarm water with no cleaning agents
particles. You can clean this filter by tapping it, then brushing it with a soft
added. It is important to let the wet parts dry thoroughly. A wet filter will be dam-
brush. After this operation is complete, you may clean a very dirty filter by
aged by vacuuming! Do not use a hair dryer to dry it!
washing and brushing with a soft brush in lukewarm water with no cleaning
Note: Wet cleaning may cause more wear and tear of the filter and, consequently,
agents added. It is important to let the wet parts dry thoroughly. A wet filter
may shorten its service life.
will be damaged by vacuuming! Do not use a hair dryer to dry it!
3. Insert the cleaned or new air outlet filter into the appliance and close the air outlet
Note: Wet cleaning may cause more wear and tear of the filter and,
grid.
consequently, may shorten its service life.
3. Insert the cleaned or new air outlet filter into the appliance and close the air
outlet grid.
TROUBLESHOOTING
Problem
Motor does not run.
Motor has stopped
operating.
Front cover cannot be
closed
Reduced suction power
Vacuum cleaner heats
up
OPTIONAL ACCESSORIES
OPTIONAL ACCESSORIES
The following appliance accessories can be purchased additionally:
The following appliance accessories can be purchased additionally:
SMS dust bags (5 units + 2 units of motor filters)
SMS dust bags (5 units + 2 units of motor filters) Order code sms9000
Fabric dust bag, 1
Fabric dust bag, 1
Motor filer
Motor filter
H.E.P.A. air outlet filter
1 2 VP9181 VP8110, VP8111, VP8112
VP 836X
Cause
Plug inserted into the mains outlet
incorrectly or insufficiently.
The mains outlet is not live.
Improper or insufficient air flow. Motor
overheating fuse activated.
Dust bag inserted incorrectly.
Dust bag full or clogged.
Obstructed filter.
Clogged nozzle, tube, or hose.
Slight heating of the vacuum cleaner is normal and cannot be considered a failure.
Order code sms9000
Order code 44291711 Price according to the applicable price list
Ord. No. ts9180
Order code 44291704 Price according to the valid price list
Order code44290910
Order code 44290911 Priced according to the valid price list
(Fig. 4)
(Fig. 5)
Solution
Check the plug connection.
Check for voltage, e.g. by connecting
another appliance.
Disconnect the cable from the socket.
Check and release the air suction
and discharge holes; check the filter's
cleanliness and/or replace the dust bag.
Let the vacuum cleaner cool down.
Check the dust filter installation.
Replace the dust bag.
Clean or replace the filter.
Check and clear the air passage on the
suction and discharge sides.
Priced according to the valid price list
Priced according to the valid price list
Price according to the applicable price list
Price according to the valid price list
EN
29 29
37
