7. Transmitter
LED Light
Trimmer
Throttle
Throttle/
Rudder
Trimmer Rudder

7.1 Binding Process

Binding is the process by which the receiver is programmed to recognize the GUID (Global Unique Identifier) code of a particular sender.
When a receiver is connected to a transmitter, the receiver responds only to that one transmitter.
LED Light
If for some reason it is necessary to re-bind, please follow these steps:
1. Turn off the transmitter. Throttle the control lever down to the lower position.
CAUTION: Keep the Gyro switch in the middle or novice position
CAUTION: Leave the aircraft in a quiet position for the gyro to be calculated.
2. Connect the battery to the aircraft and turn on the transmitter within 5 seconds.
3. The receiver LED indicator flashes for about 3-8 seconds to automatically connect.
4. When the receiver LED indicator stops flashing, the connection process is complete.
Follow the steps below if you are using normal use:
• Switch the transmitter first
• Connect the battery with the aircraft
• The LED receiver indicator flashes for a few seconds
• Shift the throttle lever up to Max and then down to Min to unlock
• Now a normal use should be feasible
DANGER: DO NOT fulfill these steps near persons or other property to avoid injury and to avoid damage.
CAUTION: Make sure that the transmitter is first turned on and then connected to the battery. If you want to switch off the transmitter, make
sure that the battery is first switched off or not connected.
26
Switch for enhanced functions e.g.
optional camera on/off
MODSTER Trainee 1200
0 - away from you: gyro off
1 - middle: soft gyro
2 - towards you: strong gyro
Gyro Switch
Trimmer
Elevator
Elevator/Aileron
Trimmer Aileron
ON/OFF
