Observing the conditions of use and the ranges of application of the present device will reduce the risk of possible
operational malfunction and contribute to extend the lifetime of your unit. Sand and other abrasive matters
contained in the liquid discharged will speed up the process of wearing and tearing and accelerate the drop in
performance. If the unit is operated properly, it will not require any maintenance.
Where applicable, you may clean the hydraulic part from sediments and dirt. This can be done by counter-flushing
the unit with clear water using a hose to be connected through the pressure port of the pump. To remove
tenacious dirt, the foot of the pump (8) can be removed by loosening the screws located at the bottom of the
pump. To avoid any hazard, any further disassembly as well as the replacement of parts must only be done by
the manufacturer or a by an authorised service provider.
Water left in the pump may freeze in case of frost and thus cause considerable damage. Therefore, the pump
must be removed from the liquid being discharged and fully drained when temperatures are below the freezing
point of the liquid. Please store the pump in a dry, frost-protected place. In the case of malfunction, you should
first of all check whether it was caused by an operating error or some other reason which cannot be attributed to a
defect of the device - for instance a power failure. The list below shows some possible malfunctions of the device,
possible causes and tips on their elimination. All the measures referred to may only be carried out with the pump
being separated from the electrical mains. If you yourself feel unable to eliminate any of these malfunctions,
please contact the customer service department or your point of sales. Any repair beyond the scope specified
below must only be performed by qualified staff. Please bear in mind that all warranty claims will become void in
the case of damage caused by inappropriate repair attempts, and that we decline any liability for any ensuing
damage.
MALFUNCTION
1. The pump is not 1. No current.
discharging any liquid,
the motor is not
running.
2. Thermal motor protection feature has
3. The capacitor is defective.
4. The pump wheel is blocked.
2. The motor is running, 1. The intake openings are clogged.
but the pump is not 2. The pressure line is clogged.
discharging any liquid. 3. Air penetrates into the pump body.
4. The min. suction level was fallen short of
5. Check valve (non-return valve), if present,
3. The pump stops after a 1. The electrical supply does not correspond
short time of operation
because the thermal
motor protection
feature has triggered. 2. Pump or intake openings are blocked by
3. Liquid is too viscous.
4. Temperature of the liquid is too high.
5. Pump is running dry.
4. Intermittent or irregular 1. Pump wheel obstructed by solid matters.
operation.
2. Refer to section 3.3.
3. Refer to section 3.4.
4. Mains voltage out of tolerance.
5. Motor or pump wheel defective.
5. Water quantity 1. Refer to section 2.1.
discharged by pump is 2. Refer to section 2.2.
inadequate. 3. Worn pump wheel.
6. The motor runs in the 1. Plug wrongly connected (wrong rotating
wrong direction.
12
POSSIBLE CAUSE
triggered. (for information on operation with
liquids > 50°C, see the note in Technical
data).
is blocked or defective.
to the information given on the type plate.
solids.
field).
Translation of the Original Operating Instructions
1. Please use a device complying with GS
(German technical supervisory authority) to
check for the presence of voltage (safety
information to be observed!). Please verify the
correct position of the plug.
2. Separate the pump from the electrical mains,
allow the system to cool down, eliminate
cause.
3. Please contact the customer service
department.
4. Eliminate blocking of pump wheel.
1. Remove possible congestion.
2. Remove possible congestion.
3. Start pump several times so that the entire air
will be driven out.
4. Make sure that the minimum suction level is
not fallen short of
5. Eliminate blocking of the check valve (non-
return valve) or replace, if damaged.
1. Please use a device complying with GS
(German technical supervisory authority) to
check the voltage of the lines of the connection
cord (safety information to be observed!).
2. Remove possible congestion.
3. Pump may not be suitable for this liquid. If
feasible, the liquid should be thinned.
4. Make sure that the temperature of the liquid
being pumped does not exceed the max.
admissible value.
5. Eliminate causes of dry-running.
1. Remove solids.
2. Refer to section 3.3.
3. Refer to section 3.4.
4. Make sure that mains voltage matches that
indicated on the type plate.
5. Please contact the customer service
department.
1. Refer to section 2.1.
2. Refer to section 2.2.
3. Please contact the customer service
department.
1. Adjust the rotating field (L1 & L2 noise).
5
ELIMINATION
