Choosing a DMX Channel Mode with 3 or 5 Channel Occupation
After having set the desired addresses and pressed ENTER, you can now choose a DMX Channel Mode.
(3 CH, 5 CH) by pressing the MODE button again. The display shows 5CH.
In case you would rather select the 3-channel mode, press the DOWN button in order to choose the 3CH
setting.
Mode:
5CH (default setting)
Press the ENTER button again to confirm and to exit the DMX Mode.
Please see the following DMX protocol graphics for the respective channel values.
DMX Protocol
5-channel mode
Channel:
Value:
1
000 – 255
Channel:
Value:
2
000 – 255
Channel:
Value:
3
000 – 255
Channel:
Value:
4
000 – 255
Channel:
Value:
000 – 000
001 – 005
5
006 – 010
011 – 255
3-channel mode
Channel:
Value:
1
000 – 255
Channel:
Value:
2
000 – 255
Channel:
Value:
3
000 – 255
Value:
3CH
Function:
Red (0 – 100%)
Function:
Green (0 – 100%)
Function:
Blue (0 – 100%)
Function:
Dimmer (0 – 100%)
Function:
Neutral
Off
Neutral
Strobe
(with increasing speed)
Function:
Red (0 – 100%)
Function:
Green (0 – 100%)
Function:
Blue (0 – 100%)
