• Power unit with aluminium housing (HxWxD: 60 x 240 x 215 mm)
• Operating unit with four-line LCD display (HxWxD: 145 x 135 x 24 mm) and backlighting,
3 m connecting cable to the power unit
• Sensor unit (safety and cabin temperature sensor) with 3.5 m silicone cable
• Instructions for assembly and use
• Drilling template
• Range of sauna mode settings:
• Nominal voltage:
• Power:
• Light:
• Ventilator function:
• Ambient temperature:
• Storage temperature:
• Heating time limit:
• Error indicator:
• Safety cut-off:
• Connection for cover protection system and/or door contact switch
• Connection for a power extension by means of a safety contactor or relay
• Extra 230 V output for coloured light or music
• Device main switch (power on/off), no standby power consumption
• Programming remains stored even after a power failure
• Child lock can be activated
• Preselection time can be activated, if combined with door contact switch or rocker
• Operating and heating time statistics of the total working time can be retrieved
EN
• Menu navigation in German, English (optionally: Italian, French, Dutch)
• Option: Connection for remote start possible, if combined with door contact switch or rocker
(start impulse or continuous contact)
20

2. PARTS LIST

3. TECHNICAL DATA

Cabin temp.: 30 - 110 °C, Operating period: 30 min - 20 hrs
400 V, 3N AC, 50 Hz
max. 11 kW with sauna mode, extensible by connection of a power
circuit breaker
230 V AC, 100 W
230 V AC, 100 W, overrun time programmable up to 60 min
0 - 40 °C
-20 - 70 °C
Adjustable up to 6 (20) hrs
Automatic error detection shown in text on the LCD-display in the event
of disconnection or damaged sensor
Over-temperature fuse in the sensor unit
