3.0 Installation

3.1 Mounting PinTherm Infra HE Connect
Determine a suitable place for installing the PinTherm Infra HE Connect. ount the PinTherm Infra
HE Connect on a solid surface that can carry a minimum of 4 kg. We recommend mounting the
PinTherm Infra HE Connect at a height of ±1.5m from the floor, at a well reachable place.
For cable gland use only cable glands fitted with strain relief, with a minimum fire class of UL94V2.
Check that the power supply has been switched off before connecting any wiring. If this is not the
case, the power supply must be switched off before you continue. When switching off the power
supply of the appliance to which connection is to be made, you should also refer to the technical
documentation/operating instructions for the appliance in question.
Connect the PinTherm Infra Connect according to one of the electrical diagrams provided at
the back of this technical manual.
Diameter Length
2
0.8mm 80 meter
2
1.0mm 100 meter
1.5mm 2 150 meter
Use a shielded data cable for this.
See technical book of the Infra HE.
