Mark PINTHERM INFRA HE CONNECT Technisches Handbuch Seite 4

• Reset option to release a burner malfunction per zone
• PIN security to modify for example switching times and temperatures
• Languages: English, French, German and Dutch
• Calibration temperature sensor: range from -3°C to +3°C per 0,5°C
• Power: 230Vac / 50Hz
• Fuse: 10A
• Modbus TCP/IP
• Embedded webserver
2.2 Technical details for external globe sensor
• Type name
• Article code
• Resistance
• Dimensions (wxhxd)
• Weight
• Electrical connection
• Degree of protection
2.3 External globe sensor resistance table
°C
-25 86,180
-20 67,640
-15 53,310
-10 42,390
-5 33,850
0 27,250
+5 22,030
2.4 Factory settings Pintherm Infra HE Connect
• Menu code
• Switching times
• Room temperature
• Calibration
4
: RSTF NTC 10K 3435
: 06 29 002
: NTC 10K 3435
: 85 x 85 x 27mm (40 mm incl. height external globe sensor)
: 42 gram
: 0.14-1.5mm²
: IP30
NTC 10K 3435
kΩ °C
+10
+15
+20
+25
+30
+35
+40
: 1000
: Block 1 MA, DI, WO, DO, VR 08:00-17:00 hrs
Block 2-7 off
: Day-time temperature 18°C
Night-time temperature 08°C
: +0.0
kΩ
17,950
14,680
12,090
10,000
8,314
6,941
5,829
