3 Operation of the appliance
verse to install new lamps (Figure 3).
Bulb
Bulb Power
3 W
Holder / Socket
GZ 10
Bulb Voltage
220 - 240 V
Size 53 x 50 mm
ILCOS Code DR/F3-220-240-GZ10-50-53
Luminous flux 250 lm
Correlated
3000 K
colour tempera-
ture
This product contains a light source of energy ef-
ficiency class "F".
3.6 Operation with chimney
connection
•
Vapour is extracted through the
flue duct, which is fastened to
the connection head on the
hood.
• The diameter of the flue duct must be the same
as the connection ring. In horizontal settings, the
pipe has to have a slight upward slope (around
10º) so that the air can exit the room easily.
3.7 Operation without chimney
connection
•
Air is filtered through the carbon
filter and recirculated in the
room. Carbon filter is used
when it is impossible to use a
flue in the house.
10 / EN
• In flueless use, remove the flaps inside the flue
adapter.
• Remove the aluminum grease filter. To install the
carbon filter, fit the filter to the tabs by centring
it on the plastic piece on both sides of the fan
body. tighten it by turning right or left.
• Replace aluminum grease filter.
Cooker Hood / User Manual
