MAIN LC-GPA FUNCTIONS:
• Electronic Launch Control System
Twisting the throttle 12 LEDs will indicate the correct RPM level to be reached
before releasing the clutch as the gate drops. A specific starting strategy will
be also activated on the ECU power map to help you getting the holeshot.
• 10 levels of Traction Control
Select and control the correct GPA level you wish on any track you are hitting.
GPA is a unique technology developed and patented by GET to let you be the
fastest coming out from the corners.
• Shift Light:
LC-GPA helps you reaching your limit, indicating the right time to shift up.
Once the RPM threshold is reached, the LEDs will flash, indicating that it is the
ideal moment to shift to obtain maximum performance.
C. LC-GPA INSTALLATION
REMEMBER TO WORK UNDER SAFETY CONDITIONS AND TO KEEP
THE ENGINE TURNED OFF.
1.
Fix the LC-GPA on the selected point of
the motorcycle. It is recommended to install
it on the front fender or, alternatively, on the
handlebar. Use the support bracket included
in the package if necessary. Use the zip ties
included in the box to properly fix the device.
EN
4
NOTE: Because of the peculiar shape
of some fenders, two metallic tubular
spacers and two rubber tubes may be
provided together with the bracket. The
spacers can be inserted into the tubes to
increase stability and vibration absorbtion.
2.
Pass the LC-GPA wiring through the
number plate. If necessary, proceed
drilling the lower part of the plate for a
better result.
3.
Connect the "MAIN" female connector
of the LC-GPA to the "MAIN" male
connector of GET ECU.
Use the extension loom (included only on specific
applications) to connect LC-GPA to GET ECU.
LC-GPA GET ECU
5
EN
