6.3.3

Pressure switch menu

Access: Touch pressure switch menu button
Function: Set the pressure switch
In the pressure switch menu the levels at which outlet pressure the generator will switch on and off, can be set. To
change the settings, touch the button in front of the text.
Button
P-switch
P-switch
Unit on
Unit off
*refer to local settings menu
To determine the correct switch on and off pressure, please check §7.4.
K3.1.142M Manual NitroFlow Lab
Selection Result
Yes Pressure switch is active
No Pressure switch is not active
0-10 Bar*/ Pressure level at which the unit will switch on
0-145 PSI*
0-10 Bar*/ Pressure level at which the unit will switch off
0-145 PSI*
in settings screen (refer to § 6.3)
- 20 -
