8

Response to power recovery

When the device is plugged in it runs a self-test, which takes
approximately 2 seconds. Initialisation is carried out once the self-
test has finished. The LED test display will indicate that initialisation
is complete: the LED will light up red, green and orange in that
order, for half a second each.
In the event of an error, the LED will flash red (one long
flash, one short flash, pause).
The device then sends a status message, which is indicated by the
device LED lighting up orange.
If the radio-controlled sensor for carbon dioxide has been taught-in
to another HomeMatic component, the LED will then light up red or
green, depending upon whether reception was confirmed (green) or
not (red).
9

Maintenance and cleaning

The device must be disconnected from the power supply before
cleaning (to do this, simply unplug it from the socket). Clean the
housing and the electrodes using a soft and dry cloth. You may
dampen the cloth a little with water in order to remove more stub-
born marks. Do not use any detergents containing solvents, as they
could corrode the plastic housing and label.
20
10

Technical data

Transmit/receive frequency:
Open air range:
Power supply:
Standby consumption:
Degree of protection:
Housing:
Housing colour:
Dimensions
(H x W x D, without plug):
Instructions for disposal
Do not dispose of the device with regular domestic waste.
Electronic devices are to be disposed of in
accordance with the Waste Electrical and Electronic
Equipment Directive via the local collection point for waste
electronic devices.
The CE sign is a free trade sign addressed exclusively to
the authorities and does not warrant any properties.
868.30 MHz
Up to 100 m
230 V/50 Hz
1.2 W
IP 20
PBT
Pure white with silver
masking frame
125 x 63 x 40 mm
21
