English; Brief Introduction; Abbreviation; Safety Instruction - Bluetti AC200MAX Handbuch

Just Power On

1. BRIEF INTRODUCTION

For I/O capability, the AC200MAX features higher continuous output power at
2,200W from its pure sine wave inverter, 100W PD3.0 USB-C port, upgraded
MPPT controller which now handles up to 900W solar input, and built-in 30A
NEMA TT-30 outlet designed for RV crowds especially.
Most significantly, considering customers' feedback, comments, and product
upgrade need, the BLUETTI AC200MAX now supports Bluetooth connection and
the new BLUETTI Smartphone App (iOS & Android) remote control.
Furthermore, the AC200MAX also supports up to 2 expandable battery packs,
using either the BLUETTI B230 or B300. With 2 BLUETTI B300, the capacity of
AC200MAX then will expand to a massive 8192Wh to run your every essential
needs at home or on the go for hours, days, or even more than a week!

2. ABBREVIATION

● BMS: Battery Management System
● MPPT: Maximum Power Point Tracking
● SOC: State of Charge
● AC: Alternating Current
● DC: Direct Current
● PV: Solar Panel(s) Charging (Photovoltaic)
● Grid: Home Power Supplied by Utility
● T500: 500W Adapter
● DOD: Depth of Discharge
● ECO Mode: A power-saving setting for the AC200MAX. When it is on, the
AC power will automatically turn off over 4 hours low load(≤50W) or no
load to save power drain.

3. SAFETY INSTRUCTION

● DO keep the AC200MAX away from the fire and heat.
● DO operate the AC200MAX in a dry and well-ventilated place. If it gets
moisturized or damp, please dry it thoroughly before use.
● DO NOT obstruct fan openings to ensure proper ventilation in use. Otherwise,
permanent damage to the AC200MAX may occur.
● DO NOT move the unit while operating as vibrations and sudden impacts
01
