1.2. Display/operating elements and connections

1 Display
2 Operation keys (up, down, left, right)
3 Enter key
4 ESC key (cancel/back)
5 Status and power LED
6 Power input
7 Fan
2021-11-03 | Technical improvements, changes in design, printing and other errors reserved. | AXING-BA_UIM-1-00.pdf
8 RF output
9 Reset button
10 NMS control interface
11 DATA interface
12 HDMI input
13 USB port
