3.4

Setting servo drive type

3.5

Programming the Timer

1. Press the arrow key until "Timer" appears in
the display and confirm with OK.
2. Choose the corresponding timer with the
arrow key and confirm with OK.
3. Set each point of "Open time" with the
arrow key and confirm each one with OK.
4. Set each desired "Open Weekday" with
the arrow key and confirm each one with OK.
Please use the same procedure for the other
timers
1. Press the arrow key until "Drive" appears in
the display
2. Confirm with OK.
3. Use the arrow key to select the servo drive type.
4. Confirm with OK.
5. Press the arrow key until > Operation <
appears in the display.
5. Set each point of "Close time" with the
arrow key and confirm each one with OK.
6. Set each desired "Close Weekday" with the
arrow key and confirm each one with OK.
7. Press the arrow key until "Back" appears in
the display and confirm with OK.
8. Press the up/down arrow key until display
shows > Operation <.
