Technical Data - Kemper KHS Timer Einbau- Und Bedienungsanleitung

Safety instructions for installation
Disposal
Local regulations on waste recycling
and disposal must be followed.
The product must not be disposed
of with household waste but must
rather be disposed of appropriately.
Danger! Only specialists with
electrical system qualifications
are permitted to carry out electrical
installation!
Note! Very strong magnetic fields can
impair the functioning.
Interference can be prevented by complying with
the installation rules below:

Technical Data

Properties
Surface mounted housing
Protection class
Own consumption
Power supply
Max. line fuse
LCD Display
- Do not mount the controller near inductive loads
(motors, transformers, contactors, etc.).
- Feed through a separate mains voltage circuit
(if necessary, with mains filter).
- Inductive loads must be equipped with protec-
tive devices to reduce overloads (varistors, RC
filter).
When using the controller together with other
devices in one system, check to see whether
that causes interference signals to be emitted.
Rigid wires must form a loop to cabling, so that
no pressure is applied to the terminals and the
housing can be closed without resistance.
160x79x58 for wall installation with calbe seal plugs
IP54
Control 3 W + consumption flushing valve(s)
230 V AC 50/60 Hz max. 3,15 A
16 A
1x16 character fields
© www.kemper-olpe.de – 11.2021 / K410068602012-00 – 19/ 32
[mm]
