...Properties
Operation
Ambient temperature range
Humidity
Alarm signal
Reset function of the alarm hold
Time control
Electrical connection
Manual operation
Relay valve switching capacity
Potential free alarm relay
Potention number of KHS quarter
turn stop valve
Potention number flushing valves
Backflow detection
Materials
Controller housing
Accessories
KHS Flush Point 230 V
KHS quarter turn stop valve with servo drive 230 V
KHS quarter turn stop valve with spring reset servo drive 230 V
(DN 15 - DN 32)
KHS quarter turn stop valve with spring reset servo drive 230 V
(DN 32 - DN 50)
KHS Drain with overflow monitoring
Flow limiter DMB
Insulation shells for quarter turn stop valves
20 / 32 – K410068602012-00 / 11.2021 – © www.kemper-olpe.de
Buttons UP|DOWN, OK, Manual
0 °C - 50 °C
0-90% non-condensing
Accoustic alarm by buzzer | Visually by LED | Alarm contact by
potential-free relays
acknowledge on unit
Real-time clock with adjustable day and week programs, auto-
matic switchover between summer-/winter time
Screwless cable terminals with operating lever
Valves can be opened and closed manually via the control
max. 230 V, 2A
max. 230 V, 2 A
based on Illustration (Typical application Item 1) 1 to 10 pcs.
each parallel operated via electrical subdistributor
based on Illustriation (Typical application Item 2) 1 pc.
via Drain with overflow monitoring
ABS
Figure 684 04
Figure 686 04
Figure 686 05
Figure 685 15
Figure 688 00
Figure 697
Figure 471 19
